Toyota Venza I (2008-2012) dome fuse engine compt) Wiring diagram
This page shows the only wiring diagram for the component.dome fuse engine compt), which is found in the car Toyota Venza I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dome fuse engine compt) (1 of 1)
5 2 4 3 1 UP CLS DWN OPN GND SLIDING ROOF CONTROL SWITCH
BACK DOOR OPENER SWITCH ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
BZR
CAN I/F
CLS
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DCTY
DOME FUSE ENGINE COMPT)
DRIVER SIDE J/B
DWN
ECU- IG 1 FUSE
GRY WIRE
HOT AT ALL TIMES DRIVER SIDE J/B (LEFT SIDE S/ROOF FUSE OF DASH)
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF
HOT IN ON OR START
J/C
LEFT FRONT DOOR COURTESY LIGHT SWITCH
LT GRN WIRE
MAIN BODY ECU
MICRO- PROCESSOR
OPN
PNK LIN WIRE
PNK WIRE
POWER SUPPLY CIRCUIT
RED WIRE
ROOF CONSOLE BOX ASSEMBLY
SLIDING ROOF CONTROL ECU (FRONT ROOF AREA)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER (LEFT REAR OF ENGINE COMPT)
YEL WIRE
Go to component -> Power top/sunroof circuit -> DOME FUSE ENGINE COMPT)
