Toyota Venza I (2008-2012) auto light control switch Wiring diagram
This page shows the only wiring diagram for the component.auto light control switch, which is found in the car Toyota Venza I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto light control switch (1 of 1)
+B (DOME)
AUTO LIGHT CONTROL SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CAN I/F
CLTB
CLTE
CLTS
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DCTY
DRIVE IC
DRIVE MONITOR SWITCH
DRIVER SIDE J/B (LEFT SIDE OF DASH)
DRL OFF (USA) OFF (EXCEPT
ECU GAUGE 1
ECU- IG 1 FUSE
ECU-ACC FUSE
FUSE
GAUGE
GRN WIRE
GRY WIRE
HAZARD SWITCH
HEAD
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT IN ON OR START
HOT W/ ACC RELAY ENERGIZED
IND
INTERIOR LIGHTS SYSTEM (LEFT KICK PANEL)
LCTY
LEFT
LEFT TURN
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MICRO- PROCESSOR
OFF
PANEL FUSE
PARKING
PCTY
PNK WIRE
POWER SUPPLY CIRCUIT
RCTY
RED WIRE
RIGHT TURN
RIGHT TURN SIGNAL SWITCH
SIDE MARKER
STOP IG 2 FUSE FUSE FUSE
TAIL
TAIL FUSE
TAIL IND (CANADA)
TAIL RELAY
TURN LEFT HEADLIGHT ASSEMBLY
TURN RIGHT HEADLIGHT ASSEMBLY
TURN SIGNAL FLASHER ASSEMBLY
USA) TAIL HEAD
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> AUTO LIGHT CONTROL SWITCH
