Toyota Tundra II (2007-2013) Integration control and panel circuit

A/C AMPLIFIER (CENTER OF DASH) BLINK BLK WIRE BLU WIRE COMBINATION METER ECU- IG 1 FUSE ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) GRN WIRE HOT IN ON OR START HOT IN ON OR START DRIVER SIDE J/B (LEFT SIDE OF DASH) INTEGRATION CONTROL, PANEL ASSEMBLY LT BLU WIRE MET FUSE ORG/ WIRE PAON PAON P-AB PBEW P-AB ILL- PNK 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 IG+ WIRE PNK WIRE RED WIRE STX WHT WIRE WHT/BLK WIRE
