Headlights circuit, double cab with drl for Toyota Tundra I facelift (2002-2006)

1 4 IG HRLY 16 5 RLCY TRLY EXTERIOR LIGHTS SYSTEM 2 3 DOOR LOCK CONTROL RECEIVER (BEHIND CENTER OF DASH) RDA PRG 25 4 8 3 22 18 9 10 BECU RRCY PCTY PKB KSW HIND RDA PRG 8 7 17 15 18 14 12 13 H-ON DIM FFOG HEAD ALTL TAIL HF HU BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLU WIRE BODY ECU (BEHIND LEFT SIDE OF DASH) COMBINATION SWITCH COURTESY 1) (AT RIGHT "B" PILLAR) COURTESY 2) (AT LEFT "B" PILLAR) DAYTIME RUNNING LIGHT RESISTOR (ON LEFT SIDE OF ENGINE COMPT, NEAR BATTERY) DCTY DIMMER RELAY DIMMER SWITCH DIODE (DOOR DRIVER SIDE J/B DRL 4 RELAY DRL FUSE ECU-B FUSE ECU-IG FUSE ENGINE COMPT, UNDER ENGINE ROOM R/B) ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B 2 (ON LEFT SIDE OF ENGINE COMPT) FOG FUSE FOG LIGHT RELAY FOGLIGHT SWITCH FUSE GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/RED WIRE H-LP RL HEAD RELAY HIGH BEAM IND HOT AT ALL TIMES HOT IN ON OR START J/C 35 (ON LEFT SIDE OF ENGINE COMPT) EA J/C 38, 39 (BEHIND LEFT KICK PANEL) J/C 50 (BEHIND CENTER OF DASH) SUB J/B 3 (BEHIND CENTER OF DASH) JUNCTION CONNECTOR 32 (ON LEFT SIDE OF JUNCTION CONNECTOR 34 (ON LEFT SIDE OF ENGINE COMPT, UNDER ENGINE ROOM R/B) JUNCTION CONNECTOR 35 JUNCTION CONNECTOR 45 (BEHIND LEFT SIDE OF DASH) LEFT FRONT DOOR COURTESY SWITCH LEFT FRONT FOG LIGHT RIGHT FRONT FOG LIGHT LEFT HEADLIGHT LEFT REAR DOOR COURTESY SWITCH LH H-LP FUSE LIGHT CONTROL SWITCH LL H-LP FUSE LOW FLASH LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT LT MAIN FUSE OFF PARKING BRAKE SWITCH COMBINATION METER PNK 1 WIRE PNK WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RH H-LP FUSE RIGHT FRONT DOOR COURTESY SWITCH RIGHT HEADLIGHT RIGHT REAR DOOR COURTESY SWITCH STARTING/CHARGING SYSTEM SUB J/B 3 (BEHIND CENTER OF DASH) SUB J/B 4 (BEHIND CENTER OF DASH) UNLOCK WARNING SWITCH (IN UPPER RIGHT SIDE OF STEERING COLUMN) VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE
