Cruise control circuit, double cab for Toyota Tundra I facelift (2002-2006)

1 2 3 8 9 22 28 26 23 29 27 +B 13 19 6 12 10 24 17 PI STP +BM 2 3 17 M- M+ ACTIVE CIRCUIT ANTI-LOCK BRAKES SYSTEM BATT MREL IGSW VPA EPA VCPA BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CCS ON/OFF CCS SPD COMBINATION METER CONTROL CIRCUIT CRUISE CONTROL SWITCH (COMBINATION SWITCH) CRUISE IND D POSITION SWITCH (PARK/NEUTRAL POSITION SWITCH) (ON TRANSMISSION) DRIVER'S SIDE J/B (UNDER LEFT END OF DASH) DRIVER'S SIDE J/B GAUGE FUSE (UNDER LEFT END OF DASH) EB (ON RIGHT REAR OF ENGINE) EFI 1 FUSE EFI RELAY ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT) ETCS FUSE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START IGN 1 FUSE IP (BEHIND CENTER IPO J/C 28, 29 (BEHIND CENTER OF DASH) J/C 34 (UNDER ENGINE ROOM R/B) J/C 35 (ON LEFT SIDE OF ENGINE COMPT) J/C 45 (BEHIND LEFT SIDE OF DASH) J/C 55 (BEHIND RIGHT SIDE OF DASH) J/C 55, 56 (BEHIND RIGHT SIDE OF DASH) LT GRN/RED WIRE OF DASH) PNK/BLU WIRE RED WIRE RED/BLU WIRE RED/YEL WIRE SHORT CONNECTOR (BEHIND LEFT SIDE OF DASH) SPEEDOMETER STOP FUSE SUB J/B 3 (BEHIND CENTER OF DASH) THROTTLE CONTROL MOTOR, POSITION SENSOR (ON THROTTLE BODY ASSEMBLY) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE
