Car Wiring Diagrams for Defogger circuit for Toyota Tercel L50 facelift (1997-1999)

BLK WIRE BLU/WHT WIRE DEF FUSE GAUGE FUSE GRN/WHT WIRE HOT AT ALL TIMES DRIVER SIDE J/B (LEFT SIDE OF DASH) HOT IN ON OR START J/C 3 (UPPER LEFT CENTER OF DASH) REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER RELAY (BEHIND CENTER LEFT OF DASH) REAR WINDOW DEFOGGER SWITCH RED/BLU WIRE TIMER CIRCUIT W/O TIMER W/TIMER WHT/BLK WIRE
