Toyota Tercel L50 facelift (1997-1999) stop light switch, high mounted stop light, stop lights, abs ecu, shift lock ecu Wiring diagram
This page shows the only wiring diagram for the component.stop light switch, high mounted stop light, stop lights, abs ecu, shift lock ecu, which is found in the car Toyota Tercel L50 facelift (1997-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop light switch, high mounted stop light, stop lights, abs ecu, shift lock ecu (1 of 1)
A/C FUSE IGN FUSE
ABS FUSE
ABS RELAY
AIRBAG SENSOR ASSEMBLY, COMBINATION METER, GENERATOR, EFI RELAY
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
CIG/ RADIO FUSE
CIGARETTE LIGHTER
COMBINATION METER, AIR BAG SENSOR ASSEMBLY, DATA LINK CONNECTOR 1
DAYTIME RUNNING LIGHT MAIN RELAY
DRIVER SIDE J/B
ECU-B FUSE DEF FUSE
ECU-IG FUSE
ENGINE ROOM R/B (LEFT FRONT INNER FENDER PANEL)
FROM ENGINE ROOM R/B (DIAGRAM 1 OF 2)
FROM FUSE BLOCK (DIAGRAM 1 OF 2)
FUSE
GAUGE FUSE
GRN WIRE
GRN/RED WIRE
GRY WIRE
IGNITION SWITCH
LT GRN WIRE
OFF
POWER FUSE
REAR WINDOW DEFOGGER RELAY, REAR WINDOW DEFOGGER SWITCH, REAR WINDOW DEFOGGER
RED/BLU WIRE
RED/GRN WIRE
STOP FUSE TAIL- LIGHT RELAY
STOP LIGHT SWITCH, HIGH MOUNTED STOP LIGHT, STOP LIGHTS, ABS ECU, SHIFT LOCK ECU
TAIL FUSE
TURN FUSE
W/ COLD WEATHER PACKAGE
W/O COLD WEATHER PACKAGE
WHT/BLK WIRE
WHT/GRN WIRE
WIPER FUSE
WIPER, WASHER WIPER, WASHER SWITCH, FRONT WIPER MOTOR, WASHER MOTOR
Go to component -> Power distribution circuit (2 of 2) -> STOP LIGHT SWITCH, HIGH MOUNTED STOP LIGHT, STOP LIGHTS, ABS ECU, SHIFT LOCK ECU
