Toyota Tercel L50 facelift (1997-1999) rear window defogger swtch Wiring diagram
This page shows the only wiring diagram for the component.rear window defogger swtch, which is found in the car Toyota Tercel L50 facelift (1997-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window defogger swtch (1 of 1)
A/C SWITCH
A/T INDICATOR ILLUMINATION (O/D MAIN SWITCH)
AUTOMATIC TRANSAXLE
BLOWER SWITCH
CLOCK
COMBINATION METER
GRN WIRE
HAZARD SWITCH
HOT AT ALL TIMES
J/C 3 (UPPER LEFT CENTER OF DASH)
J/C 5 (CENTER OF DASH)
LIGHT CONTROL SWITCH (PART OF COMBINATION SWITCH)
LT GRN WIRE
LT GRN/RED WIRE
OFF HEAD TAIL
RADIO, PLAYER
REAR WINDOW DEFOGGER SWTCH
RHEOSTAT
TAIL FUSE
TAILLIGHT RELAY
WHT/BLK WIRE
WHT/GRN WIRE
Go to component -> Instrument illumination circuit -> REAR WINDOW DEFOGGER SWTCH
