Toyota Tercel L50 facelift (1997-1999) left front door key lock and unlock switch unlock 3 2 lock Wiring diagram

ACT+ ACT- BLK/RED WIRE BLU WIRE BLU/YEL WIRE CIG/RADIO FUSE COMBINATION METER DIODE (NEAR BOTTOM OF LEFT SIDE B-PILLAR) DOME FUSE DOOR LOCKS SYSTEM DRIVER'S SIDE J/B (UNDER LEFT SIDE OF DASH) DSWD DSWH LSWD DSWP KSW LSWP ENGINE HOOD COURTESY SWITCH ENGINE ROOM R/B (ON LEFT FRONT INNER FENDER PANEL) ENGINE ROOM R/B (ON LEFT FRONT INNER FENDER PANEL) J/C EXTERIOR LIGHTS SYSTEM HORNS SYSTEM GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE HAZ-HORN FUSE HEADLIGHTS SYSTEM HORNS SYSTEM HOT AT ALL TIMES HOT IN ACC OR ON J/C 3 (CENTER OF DASH) J/C 6 (CENTER OF DASH) LEFT FRONT DOOR COURTESY SWITCH LEFT FRONT DOOR KEY LOCK AND UNLOCK SWITCH UNLOCK 3 2 LOCK LEFT FRONT DOOR LOCK CONTROL MOTOR AND UNLOCK DETECTION SWITCH LEFT REAR DOOR COURTESY SWITCH LEFT REAR DOOR LOCK CONTROL MOTOR AND UNLOCK DETECTION SWITCH LOCK LSWR CTY DSWL LT GRN WIRE LT GRN/BLK WIRE LUG HEAD SH IND LUGGAGE COMPARTMENT DOOR COURTESY SWITCH LUGGAGE COMPARTMENT DOOR KEY UNLOCK SWITCH PNK RIGHT FRONT DOOR LOCK CONTROL MOTOR AND UNLOCK DETECTION SWITCH WIRE PNK WIRE PNK/BLU WIRE POWER FUSE POWER FUSE (CENTER OF DASH) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR COURTESY SWITCH RIGHT FRONT DOOR KEY LOCK AND UNLOCK SWITCH UNLOCK RIGHT REAR DOOR COURTESY SWITCH RIGHT REAR DOOR LOCK CONTROL MOTOR AND UNLOCK DETECTION SWITCH STARTING/ CHARGING SYSTEM TAIL HORN SRLY THEFT DETERRENT IND THEFT DETERRENT, DOOR LOCK CONTROL ECU (BELOW LEFT SIDE OF DASH, AT KICK PANEL) THEFT- DETERRENT HORN UNLOCK WARNING SWITCH VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE
