Exterior lamps circuit, without trailer tow for Toyota Tacoma II (2004-2011)

4.0L BA (UNDER DRIVER'S SEAT) BD (LEFT REAR FRAME RAIL) BLU WIRE BLU/WHT WIRE BODY ECU CANADA CENTER STOP LAMP CRUISE CONTROL SYSTEM DCTY DRIVER SIDE J/B (LEFT SIDE OF DASH) EA (RIGHT FRONT FENDER) ECUB ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B (LEFT FRONT OF ENGINE COMPT) FUSE GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL J/B 1 (LEFT SIDE OF DASH) J/B FUSE ECU-B FUSE J/C 1 (BEHIND LEFT SIDE OF DASH) LEFT LICENSE PLATE LAMP LEFT PARKING LAMP LEFT REAR COMBINATION LAMP LT GRN WIRE ORG/ WIRE PCTY PNK/BLK WIRE RCTY RED WIRE RED/BLK WIRE RIGHT LICENSE PLATE LAMP RIGHT PARKING LAMP RIGHT REAR COMBINATION LAMP SIDE MARKER SKID CONTROL ECU W/ ACTUATOR (RIGHT REAR OF ENGINE COMPT) STOP FUSE STOP LAMP SWITCH (BRACKET, ABOVE BRAKE PEDAL) STOP LP CTRL RELAY (W/ HYDRAULIC BOOSTER TYPE) TAIL FUSE TAIL RELAY TAIL/STOP TURN W/ HYDRAULIC BOOSTER TYPE W/ HYDRAULIC BOOSTER TYPE W/ VACUUM BOOSTER TYPE W/ VACUUM BOOSTER TYPE WHT/ VIO WIRE WHT/BLK WIRE YEL WIRE

1 2 3 4 5 6 7 8 9 10 11 12 PNK IG TFR LR TFL LL WIRE 5 13 DRL TAIL BLK/YEL WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BODY ECU (ON J/B 1) CANADA COMBINATION METER COMBINATION SWITCH DRIVER SIDE J/B (LEFT SIDE OF DASH) DRL EA (AT RIGHT FRONT FENDER) EB (2.7L: LEFT FRONT OF ENGINE COMPT) (4.0L: NEAR BATTERY) EL ER ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B (LEFT FRONT OF ENGINE COMPT) FUSE GRN WIRE HAZARD WARNING HAZARD SIGNAL SWITCH SWITCH ASSEMBLY HEAD HOT AT ALL TIMES HOT IN ON OR START IC (CENTER OF DASH) J/C 1 (BEHIND LEFT SIDE OF DASH) J/C 13 (BEHIND RIGHT KICK PANEL) J/C 4, 5 (RIGHT SIDE OF DASH) LEFT LEFT FRONT TURN SIGNAL LAMP LEFT TURN IND LIGHT CONTROL SWITCH LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE OFF PNK WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RIGHT RIGHT FRONT TURN SIGNAL LAMP RIGHT TURN IND SHORT PIN TAIL TAIL IND (CANADA) TRN-HAZ FUSE TURN SIGNAL FLASHER (LEFT SIDE OF DASH) TURN SIGNAL SWITCH W/ DRL W/O DRL WHT WIRE WHT/BLK WIRE YEL WIRE
