Toyota Tacoma I facelift (2000-2004) Rear differential lock circuit

1 2 3 4 5 6 7 8 9 10 RLP 3.4L 2.7L A/T W/ ABS ABS ACTUATOR WITH ECU (W/ ABS) (RIGHT REAR OF ENGINE COMPT) BLK/ORG WIRE BLK/RED WIRE BLK/YEL WIRE BLU/YEL WIRE COMBINATION METER DETECTION SWITCH (TRANSFER ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) EXI FREE FUSE GAUGE FUSE GRN/ORG WIRE GRY WIRE HOT IN ON OR START IE (RIGHT END OF DASH) IG (LEFT END OF DASH) J/B 1 (BEHIND LEFT SIDE OF DASH) J/B 3 (CENTER) (BEHIND CENTER OF DASH) J/B 3 (LEFT) (ABOVE STEERING COLUMN) J/C 13 (ABOVE GLOVE BOX) LIMIT SWITCH LOCK LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT GRN/YEL WIRE M/T W/ ABS M/T W/ ABS A/T W/ ABS PNK WIRE REAR DIFFERENTIAL LOCK DETECTION SWITCH REAR DIFFERENTIAL LOCK ECU (UPPER LEFT KICK PANEL) REAR DIFFERENTIAL LOCK INDICATOR REAR DIFFERENTIAL LOCK MOTOR REAR DIFFERENTIAL LOCK SWITCH RED/BLK WIRE SPEED VIO WIRE W/ ABS OR W/ 2-4 SELECT SWITCH W/O ABS AND W/O 2-4 SELECT SWITCH WHT/BLK WIRE
