Toyota Tacoma I facelift (2000-2004) Supplemental restraint circuit

+SR P+ P- SIL D- D+ +SL 1 2 3 4 5 6 7 8 9 10 11 12 PL- PL+ AIR BAG SQUIB (FRONT PASSENGER AIR BAG ASSEMBLY) AIR BAG SQUIB (FRONT PASSENGER AIR BAG ASSEMBLY) (W/O DOUBLE CAB) AIR BAG SQUIB (STEERING WHEEL PAD) BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/WHT WIRE BUCKLE SWITCH (IN DRIVER'S SEAT BELT BUCKLE) CENTER AIR BAG SENSOR ASSEMBLY (BELOW CENTER OF DASH) COMBINATION METER DATA LINK CONNECTOR (DLC) 3 (PARTIAL) (BELOW LEFT CENTER OF DASH) 13 7 6 ECU-IG FUSE GAUGE FUSE GRN WIRE GRN/RED WIRE GRN/WHT (OR GRN/RED) WIRE GRN/WHT WIRE GRY (OR LT GRN) WIRE GRY WIRE HOT IN ON OR START IE (AROUND RIGHT EDGE OF REINFORCEMENT) IG (AROUND LEFT EDGE REINFORCEMENT) IGN FUSE J/B 1 (BEHIND DASH, LEFT OF STEERING COLUMN) J/B 3 (CENTER) (BEHIND CENTER OF DASH) J/B 3 (LEFT) (BEHIND DASH, ABOVE STEERING COLUMN) J/C 11 (ABOVE GLOVE BOX) LEFT FRONT AIR BAG SENSOR (ON LEFT FRONT OF ENGINE COMPARTMENT, BEHIND BUMPER) LEFT PRETENSIONER (AT BASE OF LEFT "B" PILLAR) LT GRN WIRE LT GRN/BLK WIRE NCA WIRE PASSENGER AIR BAG MANUAL ON/OFF INDICATOR (W/O DOUBLE CAB) PR- PR+ RED WIRE RIGHT FRONT AIR BAG SENSOR (ON RIGHT FRONT OF ENGINE COMPARTMENT, BEHIND BUMPER) RIGHT PRETENSIONER (AT BASE OF RIGHT "B" PILLAR) SL- SPIRAL CABLE SRS WARNING LIGHT TC -SR W/DOUBLE CAB W/O DOUBLE CAB WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
