Toyota Tacoma I facelift (2000-2004) washer level sensor o/d main switch key interlock solenoid wiring diagram
This page shows the only wiring diagram for the component.washer level sensor o/d main switch key interlock solenoid, which is found in the car Toyota Tacoma I facelift (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
washer level sensor o/d main switch key interlock solenoid wiring diagram (1 of 1)
1 2 W/ 2-4 SELECT SWITCH W/O 2-4 SELECT SWITCH
2-4 SELECT MOTOR
2-4 SELECT SWITCH
A/C CONTROL ASSEMBLY
AIR VENT MODE CONTROL SERVO MOTOR
AUTOMATIC DISCONNECTING DIFFERENTIAL ADD ACTUATOR
BLOWER RESISTOR
CANCEL SWITCH
CIGARETTE LIGHTER POWER OUTLET POWER OUTLET
CLOCK
CLUTCH
COMBI- NATION SWITCH
COMBINATION METER RHEOSTAT
CRUSE CONTROL ACTUATOR
CRUSE CONTROL ECU
CRUSE CONTROL SWITCH
DATA LINK CONNECTOR 3
DAYTIME RUNNING LIGHT RELAY 4 (RIGHT SIDE OF DASH)
DETECTION SWITCH
DETECTION SWITCH (NEUTRAL POSITION)
GLOVE BOX LIGHT
HEATER BLOWER SWITCH
J/B 3 (CENTER) (BEHIND CENTER OF DASH)
J/B 3 (LEFT) (BEHIND DASH, ABOVE STEERING COLUMN)
LEFT BUCKLE SWITCH
LEFT DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH, DOOR KEY LOCK/ UNLOCK SWITCH
PARKING BRAKE SWITCH
POSITION
POWER WINDOW MASTER SWITCH
REAR DIFFERENTIAL LOCK ECU PASSENGER AIR BAG CUT-OFF SWITCH (2.4L) O/D ECU
REMOTE CONTROL MIRROR SWITCH
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT END OF DASH)
SHIFT LOCK CONTROL RELAY
TO GROUND
TRANSMISSION CONTROL RELAY
UNLOCK WARNING SWITCH
W/ DBL CAB
W/O DBL CAB
W/O POWER WINDOW
WASHER LEVEL SENSOR O/D MAIN SWITCH KEY INTERLOCK SOLENOID
WHT/BLK WIRE
WIPER MOTOR
WIPER/ WASHER SWITCH
Go to component -> Ground distribution circuit (1 of 2) -> WASHER LEVEL SENSOR O/D MAIN SWITCH KEY INTERLOCK SOLENOID
