Heated seats circuit for Toyota Sienna II facelift (2005-2010)
Heated seats circuit
BH (AT LEFT "B" PILLAR)
BI (AT RIGHT "B" PILLAR)
BLK/RED WIRE
BLU/BLK WIRE
DRIVER SIDE J/B (BEHIND DASH, LEFT OF STEERING COLUMN)
DRIVER'S SEAT HEATER SWITCH
ECU-IG FUSE
FRONT PASSENGER'S SEAT HEATER SWITCH
GRN WIRE
GRY WIRE
HEATER
HOT IN ON OR START
IG (AT RIGHT KICK PANEL)
JUNCTION CONNECTOR 11, 12 (BEHIND LEFT END OF DASH)
JUNCTION CONNECTOR 18 (BEHIND UPPER LEFT SIDE OF DASH)
JUNCTION CONNECTOR 20 (BEHIND UPPER LEFT SIDE OF DASH)
JUNCTION CONNECTOR 33, 34 (BEHIND RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 44, 45 (UNDER LEFT FRONT SEAT)
LEFT SEAT HEATER ECU (UNDER LEFT FRONT SEAT)
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RIGHT SEAT HEATER ECU (UNDER RIGHT FRONT SEAT)
S-HTR FUSE
SEAT BACK)
SEAT CUSHION)
TEMP SENSOR
WHT/BLK WIRE
WHT/RED WIRE
