Immobilizer circuit for Toyota Sienna II facelift (2005-2010)

15 16 IMO IMI 4 4 CODE 5 5 TXCT 7 7 GND AGND BLK WIRE BLK/ORG WIRE BLU WIRE BLU/WHT WIRE BODY ECU (BEHIND LEFT SIDE OF DASH) BRN WIRE BRN/RED WIRE BRN/WHT WIRE CODE COMBINATION +B METER CTY DATA LINK CONNECTOR 3 (BELOW LEFT SIDE OF DASH) DRIVER SIDE J/B EFII EFIO ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) HOT AT ALL TIMES ENGINE ROOM ECU-B FUSE J/B (ON LEFT SIDE OF ENGINE COMPT) HOT IN ON OR START IE (AT LEFT KICK PANEL) IF (BEHIND LOWER CENTER OF DASH) IGN FUSE IND J/C 11, 12 (BEHIND LEFT END OF DASH) J/C 18 (BEHIND UPPER J/C 18 (BEHIND UPPER LEFT SIDE OF DASH) J/C 19 (BEHIND UPPER LEFT SIDE OF DASH) KEY AMPLIFIER LEFT FRONT DOOR COURTESY SWITCH RED WIRE RED/YEL WIRE SECURITY IND TRANSPONDER TRANSPONDER KEY AMPLIFIER (BEHIND LEFT SIDE OF DASH) TRANSPONDER KEY COMPUTER (BEHIND UPPER CENTER OF DASH) TXCT UNLOCK WARNING SWITCH (ON UPPER STEERING COLUMN) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
