Power liftgate circuit for Toyota Sienna II (2003-2005)

1 2 3 4 5 6 7 8 BD+ 2 25 21 PBDS BCTY 21 2 KSW HAZ BACK DOOR LOCK ASSEMBLY (AT LOWER LEFT CENTER OF BACK DOOR) BACK DOOR OPENER SWITCH (AT RIGHT REAR CORNER OF VEHICLE) BD- CTYO BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BM (AT LEFT REAR QUARTERPANEL) BODY ECU (BEHIND LEFT SIDE OF DASH) BRN WIRE BRN/YEL WIRE BUZZER BZR CL- CL+ GND PNK WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE J/B (BEHIND DASH, LEFT OF STEERING COLUMN) DSG DSI DSV ECU-B FUSE ECU-IG FUSE ENGINE COMPT, INSIDE ENGINE ROOM J/B) ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT) FUSIBLE LINK BLOCK (ON LEFT SIDE OF GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE HATCH DOOR HOT AT ALL TIMES HOT IN ON OR START J/C 11, 12 (BEHIND LEFT END OF DASH) J/C 13, 14 (BEHIND LEFT END OF DASH) J/C 18 (BEHIND UPPER LEFT SIDE OF DASH) J/C 19 (BEHIND UPPER LEFT SIDE OF DASH) J/C 20 (BEHIND UPPER LEFT SIDE OF DASH) J/C 3, 4 (BEHIND LEFT END OF DASH) J/C 37 (FORWARD OF LEFT REAR WHEELWELL) J/C 40 (IN BACK DOOR) J/C 41 (IN BACK DOOR) KEYLESS BUZZER (BEHIND LEFT FRONT CORNER LAMP) LEFT POWER BACK DOOR TOUCH SENSOR (AT LEFT SIDE OF BACK DOOR) LT GRN WIRE MSE MSW HAF FUL IG ECUB DC- DC+ ORG/ WIRE OSL OSE OSR PBD FUSE PNK WIRE POS POWER BACK DOOR DRIVE UNIT POWER BACK DOOR ECU (BEHIND LEFT REAR QUARTERPANEL) POWER BACK DOOR MAIN SWITCH POWER BACK DOOR WARNING BUZZER RED WIRE RED/BLU WIRE RIGHT POWER BACK DOOR TOUCH SENSOR (AT RIGHT SIDE OF BACK DOOR) SATELLITE SWITCH TURN SIGNAL FLASHER (BEHIND LEFT SIDE OF DASH) VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
