Power mirrors circuit for Toyota Sienna II (2003-2005)
Power mirrors circuit
BLK WIRE
BLU WIRE
DRIVER SIDE J/B (BEHIND DASH, LEFT OF STEERING COLUMN)
ECU-ACC FUSE
ELECTROCHROMIC CIRCUIT DEFOGGER SYSTEM
GRN WIRE
GRY WIRE
HOT IN ACC OR ON
IG (AT RIGHT KICK PANEL)
JUNCTION CONNECTOR 18 (BEHIND UPPER LEFT SIDE OF DASH)
JUNCTION CONNECTOR 20 (BEHIND UPPER LEFT SIDE OF DASH)
LEFT REMOTE CONTROL MIRROR (AT LEFT FRONT DOOR MIRROR)
LT LT
OPERATION SWITCH
PNK WIRE
RED WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT LEFT
RIGHT REMOTE CONTROL MIRROR (AT RIGHT FRONT DOOR MIRROR)
SELECT SWITCH RIGHT LEFT
UP DOWN
WHT WIRE
YEL WIRE
