Toyota Sienna I (1997-2003) rdi fuse Wiring diagrams
This page contains all the electrical diagrams for the component. rdi fuse, in which he is found in the car Toyota Sienna I (1997-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
rdi fuse wiring diagram (1 of 7)
A/C CONDENSER FAN MOTOR (ON RIGHT FRONT OF ENGINE COMPARTMENT)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
CDS FUSE
DIODE (MAGNETIC CLUTCH) (RIGHT REAR OF ENG COMPT)
ENGINE ROOM J/B 2 (ON LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE ROOM R/B 1 (ON LEFT SIDE OF ENGINE COMPARTMENT)
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
GRN WIRE
GRN/WHT WIRE
J/C 14 (BEHIND RIGHT SIDE OF DASH)
J/C 8 (BEHIND TOP CENTER OF DASH)
MAIN 1 RELAY
RADIATOR FAN MOTOR (ON LEFT FRONT OF ENGINE COMPARTMENT)
RDI FUSE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
WATER TEMPERATURE SWITCH 1 (ON REAR OF ENGINE)
WATER TEMPERATURE SWITCH 2 (ON LEFT REAR OF ENGINE)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Automatic a/c circuit, without towing package (3 of 3) -> RDI FUSE
rdi fuse wiring diagram (2 of 7)
A/C CONDENSER FAN MOTOR (ON RIGHT FRONT OF ENGINE COMPARTMENT)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
CDS FUSE
ENGINE ROOM J/B 2 (ON LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE ROOM R/B 1 (ON LEFT SIDE OF ENGINE COMPARTMENT)
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
GRN WIRE
GRN/WHT WIRE
J/C 14 (BEHIND RIGHT SIDE OF DASH)
J/C 8 (BEHIND TOP CENTER OF DASH)
MAGNETIC CLUTCH DIODE (RIGHT REAR OF ENG COMPT)
MAIN 1 RELAY
MAIN 2 RELAY
PNK PNK WIRE
PNK WIRE
RADIATOR FAN MOTOR (ON LEFT FRONT OF ENGINE COMPARTMENT)
RDI FUSE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
SHORT PIN
WATER TEMPERATURE SWITCH 1 (ON RIGHT FRONT OF ENG COMPT)
WATER TEMPERATURE SWITCH 2 (ON REAR OF ENGINE)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Automatic a/c circuit, with towing package (3 of 3) -> RDI FUSE
rdi fuse wiring diagram (3 of 7)
A/C AMPLIFIER (BEHIND RIGHT SIDE OF DASH)
A/C CONDENSER FAN MOTOR (RIGHT FRONT OF ENGINE COMPT)
A/C SINGLE PRESSURE SWITCH (RIGHT FRONT OF ENGINE COMPT)
ALT FUSE
AUTO A/C
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
CDS FUSE
DRIVER SIDE J/B (BEHIND DASH, LEFT OF STEERING COLUMN) HEATER FUSE
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE ROOM J/B 2 (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT)
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
FUSIBLE LINK BLOCK (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/C 8 (BEHIND LOWER RIGHT SIDE OF DASH)
MAGNETIC CLUTCH DIODE (RIGHT REAR OF ENGINE COMPT)
MAIN 1 RELAY
MANUAL A/C
RADIATOR FAN MOTOR (LEFT FRONT OF ENGINE COMPT)
RDI FUSE
RED WIRE
RED/WHT WIRE
WATER TEMPERATURE SWITCH 1 (REAR OF ENGINE)
WATER TEMPERATURE SWITCH 2 (LEFT REAR OF ENGINE)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Cooling fan circuit, without towing package -> RDI FUSE
rdi fuse wiring diagram (4 of 7)
A/C AMPLIFIER (BEHIND RIGHT SIDE OF DASH)
A/C CONDENSER FAN MOTOR (RIGHT FRONT OF ENGINE COMPT)
A/C SINGLE PRESSURE SWITCH (RIGHT FRONT OF ENGINE COMPT)
ALT FUSE
AUTO A/C
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
CDS FUSE
DRIVER SIDE J/B (BEHIND DASH, LEFT OF STEERING COLUMN) HEATER FUSE
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE ROOM J/B 2 (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT)
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
FUSIBLE LINK BLOCK (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/C 8 (BEHIND TOP CENTER OF DASH)
MAGNETIC CLUTCH DIODE (RIGHT REAR OF ENGINE COMPT)
MAIN 1 RELAY
MAIN 2 RELAY
MANUAL A/C
PNK PNK WIRE
PNK WIRE
RADIATOR FAN MOTOR (LEFT FRONT OF ENGINE COMPT)
RDI FUSE
RED WIRE
RED/WHT WIRE
SHORT PIN
WATER TEMPERATURE SWITCH 1 (REAR OF ENGINE)
WATER TEMPERATURE SWITCH 2 (LEFT REAR OF ENGINE)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Cooling fan circuit, with towing package -> RDI FUSE
rdi fuse wiring diagram (5 of 7)
A/C CONDENSER FAN MOTOR (ON RIGHT FRONT OF ENGINE COMPARTMENT)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
CDS FUSE
ENGINE ROOM J/B 2 (ON LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE ROOM R/B 1 (ON LEFT SIDE OF ENGINE COMPARTMENT)
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
GRN WIRE
GRN/WHT WIRE
J/C 14 (BEHIND RIGHT SIDE OF DASH)
MAIN 1 RELAY
RADIATOR FAN MOTOR (ON LEFT FRONT OF ENGINE COMPARTMENT)
RDI FUSE
RED WIRE
RED/BLU WIRE
WATER TEMPERATURE SWITCH 1 (ON REAR OF ENGINE)
WATER TEMPERATURE SWITCH 2 (ON LEFT REAR OF ENGINE)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Manual a/c circuit, without towing package (2 of 2) -> RDI FUSE
rdi fuse wiring diagram (6 of 7)
A/C CONDENSER FAN MOTOR (ON RIGHT FRONT OF ENGINE COMPARTMENT)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
CDS FUSE
ENGINE ROOM J/B 2 (ON LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE ROOM R/B 1 (ON LEFT SIDE OF ENGINE COMPARTMENT)
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
GRN WIRE
GRN/WHT WIRE
J/C 14 (BEHIND RIGHT SIDE OF DASH)
MAIN 1 RELAY
MAIN 2 RELAY
PNK PNK WIRE
PNK WIRE
RADIATOR FAN MOTOR (ON LEFT FRONT OF ENGINE COMPARTMENT)
RDI FUSE
RED WIRE
RED/BLU WIRE
SHORT PIN
WATER TEMPERATURE SWITCH 1 (ON RIGHT FRONT OF ENG COMPT)
WATER TEMPERATURE SWITCH 2 (ON REAR OF ENGINE)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Manual a/c circuit, with towing package (2 of 2) -> RDI FUSE
rdi fuse wiring diagram (7 of 7)
A/C AMPLIFIER, A/C SWITCH
A/C CONDENSER FAN MOTOR RADIATOR FAN MOTOR FAN 3 RELAY
A/C FUSE
A/F HEATER RELAY
A/F HTR FUSE
ALT FUSE
ALT-S FUSE FUSE
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLOWER MOTOR
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CDS FUSE
COMBINATION METER, LEFT SLIDE DOOR ECU ENGINE CONTROL MODULE
DIM RELAY
DOME FUSE ECU-B FUSE SHORT PIN
DRIVER SIDE R/B 5 (BEHIND LEFT SIDE OF DASH)
EFI FUSE HAZARD FUSE
EFI RELAY
ENGINE ROOM J/B 2 (ON LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 1 (LEFT SIDE OF ENG COMPT)
FAN 1 RELAY
FROM RADIO 1 FUSE (DIAGRAM 1 OF 3)
FRONT HEATER RELAY
FUSE (DIAGRAM 2 OF 3)
FUSIBLE LINK BLOCK (ON LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK MAIN (12 GA-
GENERATOR HORN SWITCH
GRN/BLK WIRE
GRN/WHT WIRE
HAZARD SWITCH
HEAD RELAY
HEADLIGHTS
HORN FUSE
HORN RELAY
HTR FUSE
INP FUSE
JUNCTION CONNECTOR 1 (NEAR LEFT HEADLIGHT)
LEFT LOW BEAM HEAD- LIGHT RIGHT LOW BEAM HEAD- LIGHT
MAIN FUSE
MAIN RELAY 1
MAIN RELAY 2
PASSENGER SIDE R/B 4 (AT RIGHT KICK PANEL)
R/B 7 (ON LEFT FRONT OF ENG COMPT)
RADIO 1 FUSE
RADIO, PLAYER, STEREO COMPONENT AMPLIFIER
RDI FUSE
REAR HEATER RELAY
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT HEAD FUSE LEFT HEAD FUSE
RIGHT HEAD LOWER FUSE LEFT HEAD LOWER FUSE
RR A/C FUSE
S/HTR FUSE
SEAT HEATER RELAY
SHORT PIN
SPLICE (DIAGRAM 2 OF 3)
THEFT DETERRENT ECU HORNS
TO ABS FUSE (DIAGRAM 3 OF 3)
TO HAZARD FUSE (DIAGRAM 1 OF 2)
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
VIO/WHT WIRE
W/O TOW PACKAGE W/ TOW PACKAGE
WHT WIRE
WHT/RED WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit (1 of 3) -> RDI FUSE
