Toyota Sienna I (1997-2003) pwr code rxck txct gnd 2 3 4 5 Wiring diagram
This page shows the only wiring diagram for the component.pwr code rxck txct gnd 2 3 4 5, which is found in the car Toyota Sienna I (1997-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pwr code rxck txct gnd 2 3 4 5 (1 of 1)
1 8 BATT MREL
16 22 +B IMLD
28 19 18 23 CODE RXCK TXCT KSW
BLK/RED WIRE
BLU/BLK WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
EFI FUSE
EFI RELAY
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE ROOM J/B 2 (ON LEFT SIDE OF ENGINE COMPT)
FORCED ENTRY CIRCUIT
HOT AT ALL TIMES
J/B 3 (BEHIND INSTRUMENT CLUSTER)
J/C 2, J/C 3 (BEHIND LEFT SIDE OF INSTRUMENT CLUSTER)
J/C 6 (BEHIND TOP CENTER OF DASH)
PWR CODE RXCK TXCT GND 2 3 4 5
RED/BLK WIRE
RED/WHT WIRE
TRANSPONDER KEY AMPLIFIER (BEHIND LEFT SIDE OF DASH)
UNLOCK WARNING SWITCH
W/ ANTI- THEFT
WHT/BLK WIRE
YEL/GRN WIRE
Go to component -> Immobilizer circuit -> PWR CODE RXCK TXCT GND 2 3 4 5
