Toyota Sienna I (1997-2003) bcty scty Wiring diagram
This page shows the only wiring diagram for the component.bcty scty, which is found in the car Toyota Sienna I (1997-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bcty scty (1 of 1)
BACK DOOR COURTESY SWITCH
BCTY SCTY
BLK WIRE
BLU WIRE
BLU/WHT WIRE
COMBINATION METER
DCTY
DIODE (COURTESY 2) (NEAR LEFT REAR WHEELHOUSE)
DIODE (COURTESY 3) (BEHIND CENTER OF DASH)
DIODE (DOME 5) (BEHIND UPPER LEFT CENTER OF DASH)
DOOR FUSE
DRIVER SIDE J/B 1 (BEHIND DASH, LEFT OF STEERING COLUMN)
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
IGNITION KEY CYLINDER LIGHT
INTEGRATION RELAY
J/B 3 (BEHIND INSTRUMENT CLUSTER)
J/C 18 (UNDERSIDE OF STEERING COLUMN)
J/C 22 (RIGHT REAR CORNER OF VEHICLE)
J/C 5 (BEHIND RIGHT SIDE OF DASH)
J/C 6 (BEHIND RIGHT SIDE OF DASH)
LEFT FRONT DOOR COURTESY SWITCH
LEFT QUARTER PANEL)
LEFT SLIDE DOOR COURTESY LIGHT
LUGGAGE COMPARTMENT LIGHT SWITCH
OPEN DOOR WARNING
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COURTESY SWITCH LEFT SLIDE DOOR COURTESY SWITCH
RIGHT SLIDE DOOR COURTESY LIGHT
RIGHT SLIDE DOOR COURTESY SWITCH
WHT WIRE
WHT/BLK WIRE
WRN
YEL WIRE
Go to component -> Courtesy lamps circuit, with door locks (2 of 2) -> BCTY SCTY
