Toyota Sienna I (1997-2003) 15 14 8 9 10 lswp lswd Wiring diagram

15 14 8 9 10 LSWP LSWD BACK DOOR KEY LOCK, UNLOCK SWITCH BACK DOOR LOCK MOTOR BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/RED WIRE BZR DCTY DOME FUSE DRIVER SIDE J/B 1 (BEHIND DASH, LEFT OF STEERING COLUMN) DRIVER SIDE J/B 1 (BEHIND DASH, LEFT OF STEERING COLUMN) DOOR FUSE ENGINE ROOM J/B 2 (ON LEFT SIDE OF ENGINE COMPT) GAUGE FUSE GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START INTEGRATION RELAY J/B 3 J/B 3 (BEHIND INSTRUMENT CLUSTER) J/C 15, J/C 16 (BEHIND UPPER RIGHT SIDE OF DASH) J/C 18 (ON UNDERSIDE OF STEERING COLUMN) J/C 22 J/C 3 (BEHIND UPPER LEFT SIDE OF DASH) J/C 4 (BEHIND UPPER LEFT SIDE OF DASH) J/C 5 J/C 5 (BEHIND UPPER RIGHT SIDE OF DASH) J/C 6 (BEHIND TOP CENTER OF DASH) KEYLESS BUZZER LEFT FRONT DOOR KEY LOCK/ UNLOCK SWITCH LEFT FRONT DOOR LOCK CONTROL SWITCH (POWER WINDOW MASTER SWITCH) LEFT FRONT DOOR LOCK MOTOR, UNLOCK DETECTION SWITCH LEFT SLIDE DOOR JUNCTION CONNECTOR (AT BASE OF LEFT "B" PILLAR) LOCK LOCK MOTOR LSWD LSWP LT GRN WIRE PCTY RED WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT DOOR COURTESY SWITCH LEFT FRONT DOOR COURTESY SWITCH RIGHT FRONT DOOR KEY LOCK/ UNLOCK SWITCH RIGHT FRONT DOOR LOCK CONTROL SWITCH RIGHT FRONT DOOR LOCK MOTOR, UNLOCK DETECTION SWITCH RIGHT SLIDE DOOR JUNCTION CONNECTOR (AT BASE OF RIGHT "B" PILLAR) UNLK UNLOCK WARNING SWITCH W/ POWER DOOR W/O POWER DOOR WHT WIRE WHT/BLK WIRE WHT/RED WIRE WIRELESS DOOR LOCK ECU (BEHIND CENTER OF DASH) YEL WIRE YEL/BLK WIRE
