Fuel door release circuit for Toyota RAV4 V (2018-2024)

Fuel door release circuit

Get access

ECM (HYBRID) EFI 1 FUSE ENGINE ROOM R/B 1 FREL FUEL FUEL LID LOCK W/ MOTOR ASSEMBLY FUEL LID OPENER SWITCH FUEL LID OPN RELAY FUEL OPN FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/EFI- MAIN 1 RELAY ENERGIZED INSTRUMENT PANEL J/B LIDO PPL PPL/BLU WIRE PPL/ORG WIRE PPL/RED WIRE RED WIRE WHT/BLK WIRE YEL WIRE
