Electric parking brake circuit, except hybrid for Toyota RAV4 V (2018-2024)
Electric parking brake circuit, except hybrid
ABS 2 FUSE
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B 1
ENGINE STOP, START ECU
GD (LEFT SIDE OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
INSTRUMENT PANEL J/B
LE-
LEFT PARKING BRAKE ACTUATOR ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MODE SELECT SWITCH (INTEGRATION CONTROL, PANEL ASSEMBLY)
MRL+
MRR
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL/BLK WIRE
PPL/BLU WIRE
PPL/RED WIRE
PPL/YEL WIRE
RE-
RED WIRE
RIGHT PARKING BRAKE ACTUATOR ASSEMBLY
SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)
VIO WIRE
W/ STOP/START SYSTEM
W/O STOP/START SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
