Power seats circuit for Toyota RAV4 V (2018-2024)
Power seats circuit
BLK WIRE
BLU WIRE
DOWN
FDWN
FRONT
FRONT VERTICAL SWITCH
FUP
GRN WIRE
GRY WIRE
HOLD
HOT AT ALL TIMES
INSTRUMENT PANEL J/B
LDWN
LEFT FRONT POWER SEAT RECLINING MOTOR (LEFT FRONT SEATBACK SPRING ASSEMBLY)
LEFT FRONT POWER SEAT SLIDE MOTOR (LEFT FRONT SEAT ADJUSTER ASSEMBLY)
LEFT FRONT POWER SEAT SWITCH
LEFT POWER SEAT LIFTER MOTOR ASSEMBLY (LEFT FRONT SEAT ADJUSTER ASSEMBLY)
LEFT POWER SEAT TILT ASSEMBLY (LEFT FRONT SEAT ADJUSTER ASSEMBLY)
LIFT SWITCH
LT GRN WIRE
LUMBAR SUPPORT SWITCH
LUP
P/SEAT F/L FUSE
PNK WIRE
RCLF
RCLR
REAR
RECLINING SWITCH
RED WIRE
RELEASE
SLDF
SLDR
SLIDE SWITCH
VIO WIRE
W/ SEAT HEATER
W/O SEAT HEATER
WHT WIRE
WHT/BLK WIRE
