Front heated seats circuit, w/o climate control seat for Toyota RAV4 V (2018-2024)
Front heated seats circuit, w/o climate control seat
BLK WIRE
BLU WIRE
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
EXCEPT HYBRID
GA (RIGHT END OF DASH)
GRN WIRE
GRY WIRE
HI IG
HOT AT ALL TIMES
LEFT SEAT HEATER (LEFT FRONT SEAT CUSHION HEATER ASSEMBLY)
LEFT SEAT HEATER SWITCH
LT BLU WIRE
LT GRN WIRE
MA (RIGHT "B" PILLAR)
NA (LEFT "B" PILLAR)
ORG/ WIRE
PNK LO WIRE
PPL/RED WIRE
R/B 5
RED WIRE
RIGHT FRONT SEAT CUSHION HEATER ASSEMBLY
RIGHT SEAT HEATER SWITCH
S/HTR F/L FUSE
S/HTR F/R FUSE
S/HTR F/R RELAY
S/HTR- MAIN FUSE
VIO WIRE
W/ MEMORY
W/ POWER SEAT
W/O MEMORY
WHT WIRE
WHT/BLK WIRE
