Power distribution circuit, hybrid for Toyota RAV4 IV facelift (2015-2019)

A/F FUSE ABS MAIN 2 FUSE ABS MTR 1 FUSE ABS MTR 2 FUSE ABS- MAIN 1 FUSE AIR CONDITIONING SYSTEM AMP FUSE ANTI-LOCK BRAKES SYSTEM BATTERY BLK WIRE BLK/WHT WIRE BLU WIRE COMPUTER DATA LINES SYSTEM D/C CUT FUSE DC/ DC-S FUSE DC/DC FUSE DOME FUSE ECU-B 1 FUSE ECU-B 2 FUSE EFI MAIN FUSE ELECTRONIC POWER STEERING SYSTEM ENGINE CONTROLS SYSTEM ENGINE CONTROLS, TRANSMISSIONS SYSTEMS ENGINE ROOM J/B ASSEMBLY EPS FUSE ETCS FUSE FUSE BLOCK ASSEMBLY FUSIBLE LINK BLOCK ASSEMBLY GRN WIRE GRY WIRE H-LP- MAIN FUSE HEADLIGHTS SYSTEM HORN FUSE HORNS SYSTEM IGCT- MAIN FUSE INSTRUMENT CLUSTER SYSTEM INV W/PMP FUSE LT BLU WIRE LT GRN WIRE MAIN FUSE PNK WIRE R/B RR-B FUSE RADIO FUSE RED WIRE SHIFT INTERLOCK SYSTEM SOUND SYSTEMS STRG LOCK FUSE SUPPLEMENTAL RESTRAINTS SYSTEM TO CERTIFICATION ECU (DIAGRAM 2 OF 4) TO ENGINE ROOM J/B 2 ASSEMBLY (DIAGRAM 4 OF 4) TO ENGINE ROOM R/B ASSEMBLY (DIAGRAM 3 OF 4) TO INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 4 OF 4) TURN, HAZ FUSE WARNING SYSTEMS WHT WIRE YEL WIRE

ACCD AIR CONDITIONING SYSTEM ANTI-LOCK BRAKES SYSTEM BLK WIRE BLU WIRE BODY COMPUTER SYSTEM BRN WIRE CERTIFICATION ECU COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM CUTB D/L BACK FUSE D/L BACK RELAY DEFOGGER SYSTEM DOOR D FUSE ECU- IG 1 FUSE ECU-IG 2 FUSE ECU-IG 3 FUSE ELECTRONIC POWER STEERING SYSTEM ENGINE CONTROLS, EXTERIOR LIGHTS SYSTEMS ENGINE SWITCH EPS-IG FUSE FROM ACC RELAY (DIAGRAM 4 OF 4) FROM ENGINE ROOM R/B ASSEMBLY (DIAGRAM 1 OF 4) FROM INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 4 OF 4) GAUGE FUSE GRN WIRE GRY WIRE HTR-IG FUSE LT BLU WIRE LT GRN WIRE MEMORY SYSTEMS MIRRORS SYSTEM NAVIGATION SYSTEM OBD FUSE ORG/ WIRE P-SEAT F/L FUSE PBD FUSE PNK WIRE POWER TOPS SYSTEM POWER WINDOWS SYSTEM RED WIRE RIGHT END OF DASH) S ROOF FUSE S/HTR F/L FUSE S/HTR F/R FUSE SEATS SYSTEM SEATS, MEMORY SYSTEMS SHIFT INTERLOCK SYSTEM SOUND, NAVIGATION SYSTEMS STOP FUSE SUPPLEMENTAL RESTRAINTS SYSTEM TO D/L 2 FUSE (DIAGRAM 3 OF 4) TO ENGINE ROOM R/B ASSEMBLY (DIAGRAM 3 OF 4) TO WIP FR FUSE (DIAGRAM 3 OF 4) TO WSH FUSE (DIAGRAM 3 OF 4) TRUNK, TAILGATE, FUEL DOORS SYSTEM VIO WIRE WARNING SYSTEMS WHT WIRE WHT/BLK WIRE WIP RR FUSE WIPER/ WASHER SYSTEM YEL WIRE

A/B FUSE AIR CONDITIONING SYSTEM BLK WIRE BLU WIRE D D/L RELAY D/L 2 FUSE D/L RELAY D/UL RELAY DEFOGGER SYSTEM ENGINE CONTROLS SYSTEM ENGINE ROOM R/B ASSEMBLY FROM ACC RELAY (DIAGRAM 4 OF 4) FROM CERTIFICATION ECU (DIAGRAM 2 OF 4) FROM DOOR D FUSE (DIAGRAM 2 OF 4) FROM ENGINE ROOM R/B ASSEMBLY (DIAGRAM 1 OF 4) FROM INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 2 OF 4) FROM METER FUSE (DIAGRAM 4 OF 4) GRY WIRE LT BLU WIRE LT GRN WIRE NAVIGATION SYSTEM PNK WIRE RED WIRE SFT LOCK- ACC FUSE SHIFT INTERLOCK SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM TO INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 4 OF 4) VIO WIRE WHT/BLK WIRE WIP FR FUSE WIPER/WASHER SYSTEM WSH FUSE YEL WIRE

ACC FUSE ACC RELAY AIR CONDITIONING SYSTEM ANTI-LOCK BRAKES SYSTEM BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM DEF FUSE DEFOGGER SYSTEM DEICER FUSE DOOR LOCKS SYSTEM DOOR R/L FUSE DOOR R/R FUSE DRL FUSE ENGINE CONTROLS SYSTEM ENGINE ROOM J/B 2 ASSEMBLY (RIGHT SIDE OF ENGINE COMPT) ENGINE ROOM R/B 2 ASSEMBLY FAN FUSE FOG FR FUSE FROM ENGINE ROOM J/B ASSEMBLY (DIAGRAM 1 OF 4) FROM ENGINE ROOM R/B ASSEMBLY (DIAGRAM 3 OF 4) GRN WIRE GRY WIRE HEADLIGHTS SYSTEM HTR FUSE IGN FUSE INSTRUMENT CLUSTER SYSTEM LT BLU WIRE LT GRN WIRE MA (RIGHT "B" PILLAR) MAIN BODY ECU METER FUSE MIRRORS SYSTEM NAVIGATION SYSTEM NOISE FILTER FUSE ORG/ WIRE P/OUTLET 1 FUSE P/OUTLET 2 FUSE P/OUTLET RELAY P/W MAIN FUSE PANEL FUSE PNK WIRE POWER OUTLET SOCKET ASSEMBLY 1 POWER OUTLET SOCKET ASSEMBLY 2 POWER RELAY POWER WINDOWS SYSTEM PTC HTR 1 FUSE PTC HTR 2 FUSE PTC HTR 3 FUSE REAR POWER OUTLET SOCKET ASSEMBLY 1 RED WIRE RIGHT END OF DASH) SEATS SYSTEM SHIFT INTERLOCK SYSTEM SOUND SYSTEMS SOUND, NAVIGATION SYSTEMS SUPPLEMENTAL RESTRAINTS SYSTEM TAIL FUSE TAIL RELAY TO A/B FUSE (DIAGRAM 3 OF 4) TO CERTIFICATION ECU (DIAGRAM 2 OF 4) TO SFT LOCK-ACC FUSE (DIAGRAM 3 OF 4) WHT WIRE WHT/BLK WIRE WIRING HARNESS CONDENSER 1 YEL WIRE
