Toyota RAV4 III (2005-2010) Headlights circuit, without drl

16 15 12 13 CANL CANH HEAD FFOG 23 20 22 8 BCTY PCTY RRCY LCTY BLK/ WHT WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DIMMER SWITCH HEADLAMP DIMMER SWITCH ASSEMBLY ECU- IG 1 FUSE ECU-B FUSE ENGINE ROOM R/B 2 FOG LIGHT SWITCH FUSE GRY WIRE HEAD LL FUSE HEAD MAIN FUSE HEAD OFF HEAD RELAY HEAD RL FUSE HF HRLY TAIL HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) LEFT LOW HEADLAMP LIGHT CONTROL SWITCH LOW FLASH FLASH LT BLU WIRE LT GRN WIRE MAIN BODY ECU OFF ON ORG/ WIRE RED WIRE RIGHT LOW HEADLAMP TAIL TAIL HEAD OFF WHT WIRE WHT/ BLK WIRE WHT/BLK WIRE

ALT FUSE BEAM IND BLK WIRE BRN WIRE CAN I/F COMBINATION METER COMPUTER DATA LINES SYSTEM ENGINE ROOM R/B 1 FR FOG FUSE FR FOG RELAY FRONT FOG IND GAUGE 2 FUSE GRN WIRE HEAD IND (USA) HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL J/B J/B 3 (LEFT SIDE OF DASH) J/B 4 (BEHIND CENTER OF DASH) LED DRIVER LEFT FRONT FOG LIGHT MAIN BODY ECU R/B 6 (LEFT SIDE OF DASH) RED WIRE RIGHT FRONT FOG LIGHT T-LP RELAY TAIL FUSE TRAY WHT WIRE WHT/ BLK WIRE WHT/BLK WIRE YEL WIRE
