Toyota RAV4 II (2000-2003) Shift interlock circuit

BLK WIRE BLU WIRE ECU-IG FUSE FUSE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START INSTRUMENT PANEL J/B (LOWER LEFT SIDE OF DASH) J/C 5 (BEHIND CENTER OF DASH) KEY INTERLOCK SOLENOID KLS+ PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH) RED WIRE SHIFT LOCK ECU (BELOW CENTER FLOOR CONSOLE) STOP FUSE STOPLIGHT SWITCH (BEHIND LEFT SIDE OF DASH) UNLOCK WARNING SWITCH WHT WIRE
