Toyota RAV4 I (1994-2000) Courtesy lamps circuit

BACK DOOR OPEN DETECTION SWITCH BLK WIRE BLU WIRE COMBINATION METER DOME FUSE DOOR DOOR IND DRIVER DOOR COURTESY SWITCH ENGINE ROOM R/B (ON LEFT FRONT STRUT TOWER) FRONT PASSENGER'S DOOR COURTESY SWITCH HOT AT ALL TIMES HOT IN RUN OR START INSTRUMENT PANEL J/B INSTRUMENT PANEL J/B (ON LOWER LEFT SIDE OF DASH) INTERIOR LIGHT) J/B 3 (BEHIND CENTER OF DASH) J/C 16 (LEFT REAR OF LUGGAGE COMPARTMENT) LEFT REAR DOOR COURTESY SWITCH OFF PERSONAL LIGHT RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR DOOR COURTESY SWITCH TURN, GAUGE FUSE W/ MOON ROOF W/O MOON ROOF 2-DOOR 4-DOOR WHT WIRE WHT/BLK WIRE YEL WIRE
