Toyota RAV4 I (1994-2000) A/c circuit

+IG 10 13 21 AC TACH ACT A/C AMPLIFIER (RIGHT SIDE OF DASH) A/C CONDENSER FAN MOTOR A/C CONTROL SWITCH A/C FUSE A/C MAGNETIC CLUTCH, LOCK SENSOR A/C THERMISTOR (RIGHT SIDE OF DASH) A/C WATER TEMPERATURE SWITCH (RIGHT FRONT OF ENGINE COMPARTMENT) ACT A/C TE LED+ BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLOWER MOTOR (RIGHT SIDE OF DASH) BLOWER RESISTOR (RIGHT SIDE OF DASH) BLOWER SWITCH (RIGHT KICK PANEL) BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE CDS FAN FUSE DEFROSTER MODE SWITCH DUAL SINGLE E/G MAIN RELAY ECU-IG FUSE ENGINE CONTROL MODULE (UNDER FRONT END OF CENTER CONSOLE) ENGINE ROOM R/B (LEFT FRONT STRUT TOWER) FAN NO.1 RELAY FAN NO.2 RELAY FAN NO.3 RELAY FUSIBLE LINK BLOCK (ON BATTERY) ALT FUSE GRN WIRE GRN/WHT WIRE HEATER RELAY HOT AT ALL TIMES HOT IN ON OR START HTR FUSE INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/B NO.3 (CENTER OF DASH) J/C 3 (BEHIND COMBINATION METER) J/C 5 (TOP CENTER OF DASH) J/C 6 (UNDER FRONT END OF CENTER CONSOLE) LO HI OFF OFF LT GRN/BLK WIRE LT LT MG/C RELAY ENGINE ROOM R/B NO.2 (IN FRONT OF LEFT STRUT TOWER) MGC SSR- SSR+ ORG/ WIRE PASSENGER SIDE R/B (RIGHT KICK PANEL) RADIATOR FAN MOTOR RDI FAN FUSE RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT SIDE OF RADIATOR) TURN, GAUGE FUSE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE
