Toyota Prius V (2023-2024) Instrument cluster circuit

A/B BKL BLK WIRE BLU WIRE COMBINATION METER ASSEMBLY 856311 856311 COMPUTER DATA LINES SYSTEM CXPI ECU-DCC 2 FUSE FE, B FUEL SUCTION TUBE W/ PUMP, GAUGE ASSEMBLY GRN WIRE GRY WIRE HAZ FUSE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED HZSW LT BLU WIRE LT GRN WIRE METER-IGR FUSE MSTI ODO OIL PRESSURE SENSOR OILW ORG/ WIRE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL/RED WIRE PPL/WHT WIRE RED WIRE SUPPLEMENTAL RESTRAINTS SYSTEM TR MSM+ TRIP SWITCH TRNL TRNR VIO WIRE WHT WIRE WHT/BLK WIRE WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY

BLK WIRE BLU WIRE BRAKE BOOSTER CONTROL ECU (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY) BRN WIRE CERTIFICATION ECU COMPUTER DATA LINES SYSTEM ELECTRIC PARKING BRAKE SWITCH ASSEMBLY ENGINE OIL LEVEL SENSOR GRN WIRE GRY WIRE LBL LT BLU WIRE LVL PNK WIRE RADIO, DISPLAY RECEIVER ASSEMBLY RED WIRE SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY) SPDO SWG VIO WIRE WHT WIRE YEL WIRE

-DP BLU WIRE BRAKE LEVEL WARNING SWITCH BRN WIRE COMPUTER DATA LINES SYSTEM CTYL CTYR CXPI ECU-DCC 2 FUSE ECU-IGR 2 FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGR 2 RELAY ENERGIZED IGR LBL LCTY LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LEFT REAR DOOR LOCK W/ MOTOR ASSEMBLY LT BLU WIRE MAIN BODY ECU (LEFT END OF DASH) MULTIPLEX NETWORK STEERING COMPUTER PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL/BLK WIRE RCTY RED WIRE RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY SPIRAL CABLE SUB-ASSEMBLY STEERING PAD SWITCH ASSEMBLY VIO WIRE WHT WIRE WHT/BLK WIRE
