Toyota Prius III facelift (2011-2015) speedometer fuel shift indicator segment vfd Wiring diagram
This page shows the only wiring diagram for the component.speedometer fuel shift indicator segment vfd, which is found in the car Toyota Prius III facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram speedometer fuel shift indicator segment vfd (1 of 1)
AIR CONDITIONING SYSTEM
BATT PCU FUSE FAN FUSE
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN CONTROLLER
CAN I/F
CHARGE IND
CLK STB NODD
COMPT)
COMPUTER DATA LINES SYSTEM
DRAWING CIRCUIT
ECO MODE IND
ECU-B 2 FUSE
ENGINE ROOM R/B 2 (RIGHT REAR OF ENGINE COMPT)
ETI ITE ILK
EV MODE IND
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) STOP FUSE
HOT IN ON OR START
IGCT 2 FUSE
IGCT 3 FUSE
IGCT 4 FUSE
IGCT RELAY
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
IWP NIWP BL PNK WIRE
LT BLU WIRE
LT GRN WIRE
MAIN IGCT FUSE
METER FUSE
MMT MMTG GMT GMTG
OPENING MULTI INFORMATION TOUCH TRACER TFT LCD
ORG/ WIRE
PNK WIRE
POWER MANAGEMENT CONTROL ECU (LEFT END OF DASH)
RED WIRE
SKID CONTROL ECU (LEFT REAR OF ENGINE COMPT)
SPEEDOMETER FUEL SHIFT INDICATOR SEGMENT VFD
VIO WIRE
VLO
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.5l, hybrid system circuit (1 of 6) -> SPEEDOMETER FUEL SHIFT INDICATOR SEGMENT VFD
