Toyota Prius III facelift (2011-2015) sio eti ite ilk air conditioning system Wiring diagram

+BATT CAN DRIVER BATT + BKUP BLK WIRE BLU WIRE BRN WIRE BUZZER I/F CHARGE IND CLK STB NODD AIR CONDITIONING SYSTEM COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ECU-B FUSE ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) EV I/F I/F EV MODE FAILURE FCTL GRN WIRE HOT AT ALL TIMES HOT IN ON OR START HOT IN ON OR START INSTRUMENT PANEL J/B MET FUSE (BEHIND LEFT END OF DASH) I/F I/F IGCT 2 FUSE IGCT 3 FUSE IGCT FUSE IGCT RELAY IGN FUSE INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) INTEGRATION RELAY IWP NIWP BL GI LT BLU WIRE MMT MMTG GMT GMTG ORG/ WIRE P LOCK FAILURE PCU FUSE PNK WIRE POWER MANAGEMENT CONTROL ECU (BEHIND RIGHT SIDE OF DASH) POWER SUPPLY IC READY RED WIRE SHIFT BY WIRE P LOCK SIO ETI ITE ILK AIR CONDITIONING SYSTEM STOP FUSE VIO WIRE VLO WHT WIRE WHT/BLK WIRE YEL WIRE
