Toyota Prius III facelift (2011-2015) p position request ind Wiring diagram
This page shows the only wiring diagram for the component.p position request ind, which is found in the car Toyota Prius III facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram p position request ind (1 of 1)
A/D
ABS IND.
BATT +
BEAM IND
BLK WIRE
BLU WIRE
BRAKE IND
BRN WIRE
BUZZER
CAN DRIVER
CHARGE IND
COMBINATION METER ASSEMBLY
CRUISE CONTROL (YELLOW) IND
DC/DC CONVERTER
DOOR IND
DRIVER'S SEAT BELT PASSENGER'S SEAT BELT IND
DYNAMIC RADAR CRUISE CONTROL (YELLOW) IND
ECO IND
ECU-B FUSE
EFI
ELECTRONIC CONTROLLED BRAKE SYSTEM IND
ELECTRONIC KEY IND
ENGINE ROOM R/B (LEFT SIDE
EV IND
EV MODE IND
EXTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM ENGINE CONTROLS SYSTEM
FLASHER
FUEL IND
GRN WIRE
GRY WIRE
HEADLIGHT BEAM LEVEL CONTROL IND
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM COMPUTER DATA LINES SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START INSTRUMENT PANEL J/B MET FUSE (BEHIND LEFT SIDE OF DASH)
HV SYSTEM IND
I/F I/F
IMAGE VFD REAL
LED HEADLIGHT IND
LT BLU WIRE
LT GRN WIRE
MAINT REQD IND
MALFUN- CTION IND LAMP
OF ENGINE COMPT)
OIL PRESSURE IND
OVERHEATED HV UNIT IND
P LOCK FAILURE IND
P POSITION REQUEST IND
PNK WIRE
POWER STEERING IND
POWER SUPPLY IC
PRE-COLLISION SYSTEM IND
READY IND
RED WIRE
SECURITY IND
SHIFT BY WIRE
SHIFT INTERLOCK SYSTEM
SLIP IND
SRS IND
TEMPERATURE CORRECTION
TEMPERATURE HOT IND
TIRE PRESSURE IND
TO ECO MODE IND (DIAGRAM 3 OF 3)
TURN L
TURN R
TURN, HAZ FUSE
VIO WIRE
WARNING SYSTEMS
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 3) -> P POSITION REQUEST IND
