Toyota Prius III facelift (2011-2015) integration control, panel assembly Wiring diagram
This page shows the only wiring diagram for the component.integration control, panel assembly, which is found in the car Toyota Prius III facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram integration control, panel assembly (1 of 1)
A/C CONTROL ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
CERTIFICATION ECU (BEHIND RIGHT SIDE OF DASH)
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
GAUGE FUSE
GLOVE BOX LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1)
GRN WIRE
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
INTEGRATION CONTROL, PANEL ASSEMBLY
J/B 3 (BEHIND LEFT SIDE OF DASH)
LIGHT CONTROL RHEOSTAT
ORG/ WIRE
PNK WIRE
POWER SWITCH 11 10 9 SWIL CANL CANH PNK WIRE
RED WIRE
RELAY ENERGIZED
STEERING SPIRAL CABLE PAD ASSEMBLY SWITCH (ON STEERING ASSEMBLY COLUMN)
SWIL
TAIL CANCEL SWITCH
TRANSMISSION SHIFT MAIN SWITCH
TRIP SWITCH (W/ SAFETY CONNECT)
WHT WIRE
WHT/BLK WIRE
Go to component -> Instrument illumination circuit (3 of 3) -> INTEGRATION CONTROL, PANEL ASSEMBLY
