Toyota Prius III facelift (2011-2015) fuse p/i 2 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse p/i 2, in which he is found in the car Toyota Prius III facelift (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse p/i 2 (1 of 6)
1 2 3 4 5 6 7 8 9 10 FR+ FL+
5 6 PNK WIRE
ADPG VAR+ VA- VAL+
BLK WIRE
BLU WIRE
BRN WIRE
CANH CANL AGND
COMPUTER DATA LINES SYSTEM
EAU
ECU-ACC FUSE
ECU-B FUSE
ECU-IG 2 FUSE
ENGINE ROOM R/B
FR- FL- GND
FUSE P/I 2
GPS ANTENNA
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START GAUGE FUSE
HOT IN ON OR START INSTRUMENT PANEL J/B IGN (BEHIND LEFT FUSE END OF DASH)
J/B 3 (BEHIND LEFT SIDE OF DASH)
J/B 4 (BEHIND RIGHT SIDE OF DASH)
J/C
LT BLU WIRE
MACC MIN+
MAIN ANTENNA
MICRO COMPUTER
MODE
NAVIGATION RECEIVER ASSEMBLY
NCA WIRE
OFF HOOK
ON HOOK
ORG/ WIRE
PNK SWG WIRE
PNK WIRE
RAD 1 FUSE
RED WIRE
SEEK
SPD SGND MIN-
SPIRAL CABLE SUB-ASSEMBLY (ON STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
STEREO JACK ADAPTER ASSEMBLY 1
TOUCH SENSOR
VIO WIRE
VOICE
VOLUME-
W/O SAFETY CONNECT
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, without radio & display amplifier with separate amplifier (1 of 4) -> FUSE P/I 2
Wiring diagram fuse p/i 2 (2 of 6)
ADPG VAR+ VA- VAL+
BLK WIRE
BLU WIRE
BRN WIRE
CANH CANL AGND
COMPUTER DATA LINES SYSTEM
EAU
ECU-B FUSE
ECU-IG 2 FUSE
ENGINE ROOM R/B
FR- FL- GND
FUSE P/I 2
GAUGE FUSE
GPS ANTENNA
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
IGN FUSE
LT BLU WIRE
MACC MIN+
MAIN ANTENNA
MET FUSE
MODE
NAVIGATION ANTENNA ASSEMBLY (RIGHT END OF DASH)
NAVIGATION RECEIVER ASSEMBLY (UNDER REAR OF CENTER CONSOLE)
NCA WIRE
OFF HOOK
ON HOOK
ORG/ WIRE
PNK SWG WIRE
PNK WIRE
RAD 1 FUSE
RED WIRE
RELAY ENERGIZED
RELAY ENERGIZED INSTRUMENT PANEL J/B ECU-ACC (BEHIND LEFT FUSE END OF DASH)
SEEK
SPD SGND MIN-
SPIRAL CABLE SUB-ASSEMBLY (ON STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
STEREO JACK ADAPTER ASSEMBLY 1
VIO WIRE
VOICE
VOLUME-
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Navigation circuit, without radio & display receiver type (1 of 4) -> FUSE P/I 2
Wiring diagram fuse p/i 2 (3 of 6)
ADPG VAR+ VA- VAL+
BLK WIRE
BLU WIRE
CANH CANL AGND
CB+
CGND
CGND V-
COMPUTER DATA LINES SYSTEM
CV+
EAU
ECU-ACC FUSE
ECU-B FUSE
ECU-IG 2 FUSE
ENGINE ROOM R/B
FUSE P/I 2
GPS ANTENNA
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START GAUGE FUSE
HOT IN ON OR START INSTRUMENT PANEL J/B IGN (BEHIND LEFT FUSE END OF DASH)
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
J/B 3 (BEHIND LEFT SIDE OF DASH)
J/B 4 (BEHIND RIGHT SIDE OF DASH)
J/C
LT BLU WIRE
MACC MIN+
MAIN ANTENNA
MICRO COMPUTER
MODE
NCA WIRE
OFF HOOK
ON HOOK
ORG/ WIRE
PARKING BRAKE SWITCH
PKB CA+ V+
PNK SWG WIRE
PNK WIRE
RAD 1 FUSE
RADIO, DISPLAY RECEIVER ASSEMBLY
RED WIRE
SEEK
SPD SGND MIN-
SPIRAL CABLE SUB-ASSEMBLY (ON STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
STEREO JACK ADAPTER ASSEMBLY 1
TOUCH SENSOR
VIO WIRE
VOICE
VOLUME-
W/O SAFETY CONNECT
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, with radio & display amplifier & separate amplifier (1 of 5) -> FUSE P/I 2
Wiring diagram fuse p/i 2 (4 of 6)
1 2 3 4 5 6 7 8 9 10 FR+ FL+
5 6 PNK WIRE
ADPG VAR+ VA- VAL+
BLK WIRE
BLU WIRE
BRN WIRE
CANH CANL AGND
COMPUTER DATA LINES SYSTEM
EAU
ECU-ACC FUSE
ECU-B FUSE
ECU-IG 2 FUSE
ENGINE ROOM R/B
FR- FL- GND
FUSE P/I 2
GPS ANTENNA
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START GAUGE FUSE
HOT IN ON OR START INSTRUMENT PANEL J/B IGN (BEHIND LEFT FUSE END OF DASH)
J/B 3 (BEHIND LEFT SIDE OF DASH)
J/B 4 (BEHIND RIGHT SIDE OF DASH)
J/C
LT BLU WIRE
MACC MIN+
MAIN ANTENNA
MICRO COMPUTER
MODE
NAVIGATION RECEIVER ASSEMBLY
NCA WIRE
OFF HOOK
ON HOOK
ORG/ WIRE
PNK SWG WIRE
PNK WIRE
RAD 1 FUSE
RED WIRE
SEEK
SPD SGND MIN-
SPIRAL CABLE SUB-ASSEMBLY (ON STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
STEREO JACK ADAPTER ASSEMBLY 1
TOUCH SENSOR
VIO WIRE
VOICE
VOLUME-
W/O SAFETY CONNECT
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, without radio & display amplifier with separate amplifier (1 of 4) -> FUSE P/I 2
Wiring diagram fuse p/i 2 (5 of 6)
ADPG VAR+ VA- VAL+
BLK WIRE
BLU WIRE
BRN WIRE
CANH CANL AGND
COMPUTER DATA LINES SYSTEM
EAU
ECU-B FUSE
ECU-IG 2 FUSE
ENGINE ROOM R/B
FR- FL- GND
FUSE P/I 2
GAUGE FUSE
GPS ANTENNA
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
IGN FUSE
LT BLU WIRE
MACC MIN+
MAIN ANTENNA
MET FUSE
MODE
NAVIGATION ANTENNA ASSEMBLY (RIGHT END OF DASH)
NAVIGATION RECEIVER ASSEMBLY (UNDER REAR OF CENTER CONSOLE)
NCA WIRE
OFF HOOK
ON HOOK
ORG/ WIRE
PNK SWG WIRE
PNK WIRE
RAD 1 FUSE
RED WIRE
RELAY ENERGIZED
RELAY ENERGIZED INSTRUMENT PANEL J/B ECU-ACC (BEHIND LEFT FUSE END OF DASH)
SEEK
SPD SGND MIN-
SPIRAL CABLE SUB-ASSEMBLY (ON STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
STEREO JACK ADAPTER ASSEMBLY 1
VIO WIRE
VOICE
VOLUME-
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit, without radio & display receiver type (1 of 4) -> FUSE P/I 2
Wiring diagram fuse p/i 2 (6 of 6)
ADPG VAR+ VA- VAL+
BLK WIRE
BLU WIRE
CANH CANL AGND
CB+
CGND
CGND V-
COMPUTER DATA LINES SYSTEM
CV+
EAU
ECU-ACC FUSE
ECU-B FUSE
ECU-IG 2 FUSE
ENGINE ROOM R/B
FUSE P/I 2
GPS ANTENNA
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START GAUGE FUSE
HOT IN ON OR START INSTRUMENT PANEL J/B IGN (BEHIND LEFT FUSE END OF DASH)
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
J/B 3 (BEHIND LEFT SIDE OF DASH)
J/B 4 (BEHIND RIGHT SIDE OF DASH)
J/C
LT BLU WIRE
MACC MIN+
MAIN ANTENNA
MICRO COMPUTER
MODE
NCA WIRE
OFF HOOK
ON HOOK
ORG/ WIRE
PARKING BRAKE SWITCH
PKB CA+ V+
PNK SWG WIRE
PNK WIRE
RAD 1 FUSE
RADIO, DISPLAY RECEIVER ASSEMBLY
RED WIRE
SEEK
SPD SGND MIN-
SPIRAL CABLE SUB-ASSEMBLY (ON STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
STEREO JACK ADAPTER ASSEMBLY 1
TOUCH SENSOR
VIO WIRE
VOICE
VOLUME-
W/O SAFETY CONNECT
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, with radio & display amplifier & separate amplifier (1 of 5) -> FUSE P/I 2
