Toyota Prius III facelift (2011-2015) 11 36 37 38 pnk lbl computer data lines system Wiring diagram
This page shows the only wiring diagram for the component.11 36 37 38 pnk lbl computer data lines system, which is found in the car Toyota Prius III facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 11 36 37 38 pnk lbl computer data lines system (1 of 1)
11 36 37 38 PNK LBL COMPUTER DATA LINES SYSTEM WIRE
BATT +
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL WARNING SWITCH (BRAKE FLUID RESERVOIR)
BRN WIRE
CANADA USA
COMBINATION METER ASSEMBLY
CRUISE CONTROL
DCM (W/ SAFETY CONNECT)
DYNAMIC RADAR
ECO MODE IND
ENGINE COOLANT
FROM EV MODE IND (DIAGRAM 1 OF 3)
FRONT FOG IND
GRN WIRE
GRY WIRE
HAZARD WARNING SIGNAL SWITCH ASSEMBLY
HEAD IND TAIL IND
HOUR
LIGHT (GREEN) IND
LT BLU WIRE
LT GRN WIRE
PNK MIN WIRE
PNK SIGN WIRE
PNK WIRE
POWER MODE IND
RADIO, DISPLAY
RECEIVER ASSEMBLY, NAVIGATION RECEIVER ASSEMBLY
RED WIRE
RST
SET IND
SKID CONTROL ECU W/ ACTUATOR ASSEMBLY
SPDI
SPDR
SPIRAL CABLE SUB-ASSEMBLY W/ SENSOR
STEERING PAD SWITCH ASSEMBLY
TEMPERATURE SENSOR
TRIP SWITCH
VIO WIRE
W/ NAVIGATION RECEIVER ASSEMBLY TYPE
W/ READIO, DISPLAY RECEIVER TYPE
WHT WIRE
WHT/BLK WIRE
Go to component -> Instrument cluster circuit (3 of 3) -> 11 36 37 38 PNK LBL COMPUTER DATA LINES SYSTEM WIRE
