Toyota Prius III (2009-2011) Courtesy lamps circuit

13 14 CANL CANH 9 10 11 CANH CANL SWIL PNK WIRE BACK DOOR LOCK ASSEMBLY (CENTER REAR OF LUGGAGE COMPT) BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COURTESY CTY CTY DOOR DCTY DIODE (BACK DOOR COURTESY LIGHT) DIODE (LEFT FRONT COURTESY LIGHT) DIODE (RIGHT FRONT COURTESY LIGHT) DOOR 1 FUSE DOOR OFF ECU- IG 1 FUSE ECU-ACC FUSE ECU-B FUSE FSPT GRN WIRE HOT AT ALL TIMES HOT AT ALL TIMES ENGINE ROOM R/B DOME (LEFT SIDE FUSE OF ENGINE COMPT) HOT W/ ACC RELAY ENERGIZED IG ALTB INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) J/B 3 (BEHIND LEFT SIDE OF DASH) LEFT "C" PILLAR) LEFT FRONT DOOR COURTESY LIGHT ASSEMBLY LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (LEFT "B" PILLAR) LEFT FRONT MAP LIGHT SWITCH LEFT INTERIOR ILLUMINATION LIGHT ASSEMBLY 1 (IF EQUIPPED) LEFT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY (LEFT "C" PILLAR) LEFT VANITY LIGHT ASSEMBLY LEFT VISOR ASSEMBLY LT BLU WIRE MAIN BODY ECU INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) MAP LIGHT ASSEMBLY ORG/ WIRE POWER SWITCH RED WIRE RIGHT FRONT DOOR COURTESY LIGHT ASSEMBLY RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (RIGHT "B" PILLAR) RIGHT FRONT MAP LIGHT SWITCH RIGHT INTERIOR ILLUMINATION LIGHT ASSEMBLY 1 (IF EQUIPPED) RIGHT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY (RIGHT "C" PILLAR) RIGHT VANITY LIGHT ASSEMBLY RIGHT VISOR ASSEMBLY ROOM LIGHT ASSEMBLY 1 ROOM LIGHT ASSEMBLY 2 SWIL VIO WIRE W/O SLIDING ROOF W/ SLIDING ROOF WHT WIRE WHT/BLK WIRE YEL WIRE
