Toyota Prius III (2009-2011) ppos mth- mth+ hsdn req- req+ Wiring diagram
This page shows the only wiring diagram for the component.ppos mth- mth+ hsdn req- req+, which is found in the car Toyota Prius III (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppos mth- mth+ hsdn req- req+ (1 of 1)
ACCELERATOR PEDAL SENSOR (ON ACCELERATOR PEDAL ASSEMBLY)
ANTI-THEFT SYSTEM
BLK WIRE
BLK/ WHT WIRE
BLU WIRE
BRN WIRE
CLK- CLK+ PCON STP HTM+ HTM-
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
ENGINE ROOM R/B (LEFT SIDE OF
FUSE ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGF
IGNITION COIL 1 (TOP OF ENGINE)
IGNITION COIL 2 (TOP OF ENGINE)
IGNITION COIL 3 (TOP OF ENGINE)
IGNITION COIL 4 (TOP OF ENGINE)
IMO IMI CCS
J/B 3 (BEHIND LEFT SIDE OF DASH)
LT GRN WIRE
MREL ST-
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
POWER MANAGEMENT CONTROL ECU (BEHIND RIGHT SIDE OF DASH)
PPOS MTH- MTH+ HSDN REQ- REQ+
RED WIRE
SKID CONTROL ECU (LEFT REAR OF ENGINE COMPT)
STOP LIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
TOP OF ENGINE)
TRANSMISSIONS SYSTEM
TRANSMISSIONS SYSTEM ANTI-LOCK BRAKES SYSTEM
VIO WIRE
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.8l, hybrid system circuit (6 of 6) -> PPOS MTH- MTH+ HSDN REQ- REQ+
