Toyota Prius III (2009-2011) p/i 2 fuse of engine compt) Wiring diagram
This page shows the only wiring diagram for the component.p/i 2 fuse of engine compt), which is found in the car Toyota Prius III (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram p/i 2 fuse of engine compt) (1 of 1)
1 2 3 4 5 6 HOLD
31 22 32 ALTB
AUTO OFF
BLK WIRE
BLU WIRE
BRN WIRE
DOOR 1 FUSE
ECU- IG 1 FUSE
ECU-ACC FUSE
ECU-B FUSE
ECU-IG 2 FUSE
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B (LEFT SIDE
FRONT WASHER SWITCH
FRWA PB
GAUGE FUSE
GRN WIRE
H-LP CLN FUSE
HEAD
HEADLIGHT CLEANER MOTOR, PUMP (RIGHT FRONT CORNER OF ENGINE COMPT)
HEADLIGHT CLEANER RELAY (NEAR RIGHT HEADLIGHT ASSEMBLY)
HEADLIGHT CLEANER SWITCH ASSEMBLY
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
INTEGRATION RELAY
J/B 3 (BEHIND LEFT SIDE OF DASH)
LIGHT CONTROL SWITCH
LT GRN WIRE
MAIN BODY ECU
P/I 2 FUSE OF ENGINE COMPT)
RED WIRE
RELAY ENERGIZED
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
YEL WIRE
Go to component -> Headlamp washer circuit -> P/I 2 FUSE OF ENGINE COMPT)
