Toyota Prius III (2009-2011) navigation receiver assembly, radio receiver assembly Wiring diagram
This page shows the only wiring diagram for the component.navigation receiver assembly, radio receiver assembly, which is found in the car Toyota Prius III (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram navigation receiver assembly, radio receiver assembly (1 of 1)
1 2 CANH CANL
11 35 34 PNK TC WIRE
12 11 CANL CANH
13 22 CANH CANL
13 5 7 4 12 PNK CANH CANL TC CANN CANP WIRE
25 24 22 21 TX+ TX- CANH CANL PNK WIRE
3 4 PNK WIRE
5 15 ATX+ ATX-
7 8 TX+ TX-
9 10 PNK WIRE
A/C AMPLIFIER ASSEMBLY (BEHIND CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CENTER AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE)
COLLISION SYSTEM) (BEHIND RIGHT SIDE OF DASH)
DRIVING SUPPORT ECU (W/ PRE-
ECM (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
LANE RECOGNITION CAMERA SENSOR (W/ LANE KEEPING ASSIST) (CENTER FRONT OF ROOF)
LT GRN WIRE
NAVIGATION RECEIVER ASSEMBLY, RADIO RECEIVER ASSEMBLY
PARKING ASSIST ECU (W/ INTELLIGENT PARKING ASSIST) (BEHIND RIGHT SIDE OF DASH)
PNK WIRE
POWER MANAGEMENT CONTROL ECU (BEHIND RIGHT SIDE OF DASH)
RED WIRE
SEAT BELT CONTROL ECU (W/ PRE- COLLISION SYSTEM) (BEHIND RIGHT SIDE OF DASH)
ST-PLUG 3 2
STEREO COMPONENT AMPLIFIER (IF EQUIPPED) (UNDER FRONT PASSENGER'S SEAT)
TRANSMISSION CONTROL ECU (BEHIND RIGHT SIDE OF DASH)
VIO WIRE
W/ PRE-COLLISION SYSTEM, W/ INTELLIGENT PARKING ASSIST
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Computer data lines circuit (2 of 2) -> NAVIGATION RECEIVER ASSEMBLY, RADIO RECEIVER ASSEMBLY
