Toyota Prius III (2009-2011) multiplex network master switch assembly wiring diagram
This page shows the only wiring diagram for the component.multiplex network master switch assembly, which is found in the car Toyota Prius III (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
multiplex network master switch assembly wiring diagram (1 of 1)
AUTO
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL CIRCUIT
D FR DOOR FUSE
DOOR LOCK SWITCH
DOOR R/L FUSE
DOWN
DOWN UP 15 20
DRIVER SIDE AUTO SWITCH
DRIVER SIDE DOWN SWITCH
DRIVER SIDE P/W MANUAL OUTPUT CIRCUIT
DRIVER SIDE UP SWITCH
DRIVER'S DOOR
ECU-B FUSE
ENGINE ROOM R/B
FRONT PASSENGER SIDE CONTROL SWITCH
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
J/B 3 (BEHIND LEFT SIDE OF DASH)
LED
LEFT FRONT DOOR COURTESY LIGHT SWITCH (LEFT "B" PILLAR)
LEFT FRONT POWER WINDOW REGULATOR MOTOR
LEFT REAR SIDE CONTROL SWITCH
LIN
LOCK
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
P FR DOOR FUSE
PNK LIN WIRE
PNK PNK WIRE
PNK WIRE
RED WIRE
RIGHT FRONT POWER WINDOW REGULATOR MOTOR
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT REAR SIDE CONTROL SWITCH
UNLOCK
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WINDOW LOCK SWITCH
YEL WIRE
Go to component -> Power windows circuit (1 of 2) -> MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
