Toyota Prius III (2009-2011) left rear power window regulator Wiring diagram
This page shows the only wiring diagram for the component.left rear power window regulator, which is found in the car Toyota Prius III (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear power window regulator (1 of 1)
BRAKE FLUID LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY)
BRN WIRE
COMBINATION METER ASSEMBLY
ENGINE HOOD COURTESY SWITCH ASSEMBLY
FUEL SENDER GAUGE BACK DOOR LOCK ASSEMBLY ASSEMBLY
HEADLIGHT CLEANER RELAY
LEFT "C" PILLAR)
LEFT LICENSE PLATE LIGHT ASSEMBLY
LEFT LUMBAR SUPPORT SWITCH (LEFT POWER SEAT SWITCH)
LEFT REAR
LEFT REAR COMBINATION LIGHT ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR
LEFT SEAT HEATER CONTROL SUB-ASSEMBLY
PNK WIRE
POWER WINDOW LEFT REAR REGULATOR DOOR W/ MOTOR MOTOR LOCK ASSEMBLY ASSEMBLY
RADIO NAVIGATION RECEIVER RECEIVER ASSEMBLY ASSEMBLY
RIGHT LICENSE PLATE LIGHT ASSEMBLY
SKID CONTROL ECU W/ ACTUATOR ASSEMBLY
STOP LIGHT CONTROL RELAY ASSEMBLY
SWITCH ASSEMBLY
TIRE PRESSURE WARNING ECU
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER
Go to component -> Ground distribution circuit (1 of 4) -> LEFT REAR POWER WINDOW REGULATOR
