Toyota Prius III (2009-2011) led drive module Wiring diagrams
This page contains all the electrical diagrams for the component. led drive module, in which he is found in the car Toyota Prius III (2009-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram led drive module (1 of 2)
1 2 3 HLOR DRLS
BLK WIRE
BLU WIRE
BRN WIRE
CAN I.C
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY
DRL RELAY ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
ECU-B FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
EXCEPT LED TYPE
FUSE
H-LP HI MAIN FUSE
H-LP LH-HI
H-LP RH HI FUSE
HLOL +B
HOT AT ALL TIMES
LED DRIVE MODULE
LED TYPE EXCEPT LED TYPE
LEFT FOG LIGHT ASSEMBLY
LEFT HEADLIGHT ASSEMBLY
LEFT HEADLIGHT ASSEMBLY (LED TYPE)
LOW (LED)
LT GRN WIRE
P/I 2 FUSE
PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER)
PNK WIRE
RED WIRE
RIGHT FOG LIGHT ASSEMBLY
RIGHT HEADLIGHT ASSEMBLY
RIGHT HEADLIGHT ASSEMBLY (LED TYPE)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Headlamps & fog lamps circuit, with drl (2 of 2) -> LED DRIVE MODULE
Wiring diagram led drive module (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CAN I.C
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DIM RELAY
DISPLAY
ECU-B FUSE
ENGINE ROOM R/B
EXCEPT LED TYPE
FUSE
H-LP HI MAIN FUSE
H-LP LH-HI
H-LP RH HI FUSE
HOT AT ALL TIMES
LED DRIVE MODULE
LED TYPE EXCEPT LED TYPE
LEFT FOG LIGHT ASSEMBLY
LEFT HEADLIGHT ASSEMBLY
LEFT HEADLIGHT ASSEMBLY (LED TYPE)
LOW (LED)
LT GRN WIRE
P/I 2 FUSE
PNK WIRE
RED WIRE
RIGHT FOG LIGHT ASSEMBLY
RIGHT HEADLIGHT ASSEMBLY (EXCEPT LED TYPE)
RIGHT HEADLIGHT ASSEMBLY (LED TYPE)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Headlamps & fog lamps circuit, without drl (2 of 2) -> LED DRIVE MODULE
