Toyota Prius III (2009-2011) integration control, panel steering assembly sensor Wiring diagram
This page shows the only wiring diagram for the component.integration control, panel steering assembly sensor, which is found in the car Toyota Prius III (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram integration control, panel steering assembly sensor (1 of 1)
A/C AMPLIFIER ASSEMBLY
BATTERY LOCK VOLTAGE SWITCH SENSOR
BLK WIRE
BLU WIRE
CENTER AIR BAG SENSOR ASSEMBLY
FROM
FROM GROUND
FRONT BLOWER W/ FAN MOTOR SUB- ASSEMBLY
GLOVE BOX LIGHT ASSEMBLY (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1)
GRN WIRE
HEADLIGHT DIMMING SWITCH ASSEMBLY
HV BATTERY OCCUPANT JUNCTION DETECTION BLOCK ECU ASSEMBLY
INTEGRATION CONTROL, PANEL STEERING ASSEMBLY SENSOR
INTER
ION GENERATOR A/C SUB- CONTROL ASSEMBLY ASSEMBLY
J/B 3 (BEHIND LEFT SIDE OF DASH)
LEFT FRONT DOOR LOCK ASSEMBLY
LEFT FRONT DOOR OUTSIDE HANDLE ASSEMBLY
LEFT OUTER REAR VIEW MOTOR ASSEMBLY
LEFT VISOR ASSEMBLY
LEVER POSITION SENSOR 2
MAP LIGHT ASSEMBLY
OUTER MIRROR SWITCH ASSEMBLY
PASSENGER SEAT BELT WARNING LIGHT ASSEMBLY
POWER MANAGEMENT CONTROL ECU
POWER SWITCH
RIGHT REAR COMBINATION LIGHT ASSEMBLY
RIGHT REAR DOOR W/ MOTOR LOCK ASSEMBLY
RIGHT VISOR ASSEMBLY
SLIDING ROOF CONTROL ECU
SOLAR BATTERY AIR CONDITIONING BLOWER VENT ECU
SPIRAL CABLE SUB-ASSEMBLY
TIRE PRESSURE WARNING RESET SWITCH
TRANSMISSION SHIFT MAIN SWITCH
TRIP SWITCH
VIO WIRE
W/ SLIDING ROOF
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER JUNCTION SWITCH CONNECTOR ASSEMBLY
YAW RATE SENSOR ASSEMBLY
Go to component -> Ground distribution circuit (4 of 4) -> INTEGRATION CONTROL, PANEL STEERING ASSEMBLY SENSOR
