Car Wiring Diagrams for Toyota Prius III (2009-2011) - Wiring diagrams inner rear view mirror assembly

Wiring diagram inner rear view mirror assembly (1 of 5)

Get access

1 2 3 4 5 6 7 8 9 10 IG DOME FUSE ECU-IG 2 FUSE ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) HOT AT ALL TIMES INNER REAR VIEW MIRROR ASSEMBLY INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) J/B 3 (BEHIND LEFT SIDE OF DASH) ORG/ WIRE RED WIRE RELAY ENERGIZED WHT/BLK WIRE

Get access

1 2 3 4 5 6 7 8 9 10 11 12 13 14 IG BLK WIRE CB+ CGND CGND CB+ CV+ CV- CV+ +B DOME R/B FUSE (LEFT SIDE OF ENGINE COMPT) ECU-IG 2 FUSE ENGINE INTEGRATION ROOM RELAY J/B (LEFT SIDE OF ENGINE COMPT) NAV ENGINE ROOM HOT AT ALL TIMES INNER REAR VIEW MIRROR ASSEMBLY INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) J/B 3 (BEHIND LEFT SIDE OF DASH) NCA WIRE ORG/ WIRE PNK REV WIRE PNK WIRE REAR TELEVISION CAMERA (LEFT SIDE OF LIFTGATE) RED WIRE RELAY ENERGIZED WHT WIRE WHT/BLK WIRE

Get access

ECU-IG 2 FUSE INNER REAR VIEW MIRROR ASSEMBLY INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) J/B 3 (BEHIND LEFT SIDE OF DASH) ORG/ WIRE RELAY ENERGIZED WHT/BLK WIRE

Get access

BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY BLU WIRE BRN WIRE CRANKSHAFT POSITION SENSOR SHIELD DLC 3 DRIVING SUPPORT ECU ASSEMBLY ENGINE CONTROL MODULE (ECM) GRN WIRE HEADLIGHT CLEANER SWITCH ASSEMBLY INNER REAR VIEW MIRROR ASSEMBLY INTEGRATION CONTROL, PANEL ASSEMBLY J/B 3 (BEHIND LEFT SIDE OF DASH) J/B 4 (BEHIND RIGHT SIDE OF DASH) LANE RECOGNITION CAMERA SENSOR ASSEMBLY MAIN ID CODE BODY BOX ECU MILLIMETER WAVE RADAR PARKING SEAT SENSOR ASSIST HEATER ASSEMBLY ECU SWITCH NCA WIRE OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD PRE-COLLISION SYSTEM CANCEL SWITCH ASSEMBLY RADIO RECEIVER ASSEMBLY RIGHT FRONT DOOR LOCK ASSEMBLY RIGHT FRONT DOOR OUTSIDE HANDLE ASSEMBLY RIGHT OUTER REAR VIEW MIRROR ASSEMBLY SEAT HEATER SWITCH SOLAR VENTILATION RELAY STEREO COMPONENT TUNER ASSEMBLY TO GROUND TOP OF ENGINE) TRANSMISSION SHIFT MAIN A/C CONTROL SWITCH ASSEMBLY TRIP SWITCH TURN SIGNAL CERTIFICATION FLASHER ECU ASSEMBLY ASSEMBLY VENTILATOR SWITCH VIO WIRE W/ STEREO COMPONENT AMPLIFIER, W/ NAVIGATION SYSTEM W/O NAVIGATION SYSTEM WHT WIRE WHT/BLK WIRE

Get access

1 2 3 4 5 6 7 8 9 10 11 12 13 14 IG BLK WIRE CB+ CGND CGND CB+ CV+ CV- CV+ +B DOME R/B FUSE (LEFT SIDE OF ENGINE COMPT) ECU-IG 2 FUSE ENGINE INTEGRATION ROOM RELAY J/B (LEFT SIDE OF ENGINE COMPT) NAV ENGINE ROOM HOT AT ALL TIMES INNER REAR VIEW MIRROR ASSEMBLY INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) J/B 3 (BEHIND LEFT SIDE OF DASH) NCA WIRE ORG/ WIRE PNK REV WIRE PNK WIRE REAR TELEVISION CAMERA (LEFT SIDE OF LIFTGATE) RED WIRE RELAY ENERGIZED WHT WIRE WHT/BLK WIRE
