Toyota Prius III (2009-2011) 4 1 led type except led type Wiring diagram
This page shows the only wiring diagram for the component.4 1 led type except led type, which is found in the car Toyota Prius III (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4 1 led type except led type (1 of 1)
+ECU
4 1 LED TYPE EXCEPT LED TYPE
5 2 LED TYPE EXCEPT LED TYPE
BLK WIRE
BLU WIRE
BRN WIRE
ECU-IG
EL ER
FRCY FLCY BECU
FUSE
GRN WIRE
HAZARD SWITCH
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT IN ON OR ACC
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
INTEGRATION CONTROL, PANEL ASSEMBLY
J/B 3 (BEHIND LEFT SIDE OF DASH) 1 2 3 4 5 6 7 8 IG LR LL
LEFT
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT ASSEMBLY
LRCY TAIL GND BCTY
MAIN BODY ECU
MARKER
OFF
ORG/ WIRE
PARKING
PNK WIRE
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT ASSEMBLY
TAIL FUSE
TAIL LIGHT CONTROL SWITCH HEAD AUTO
TAIL RELAY
TURN SIGNAL FLASHER (BEHIND LEFT END OF DASH)
TURN SWITCH RIGHT
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> 4 1 LED TYPE EXCEPT LED TYPE
