Toyota Prius III (2009-2011) 1 4 2 5 rda gnd rssi Wiring diagram
This page shows the only wiring diagram for the component.1 4 2 5 rda gnd rssi, which is found in the car Toyota Prius III (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 4 2 5 rda gnd rssi (1 of 1)
1 2 CLSW SPD TC TACH IND
1 4 2 5 RDA GND RSSI
10 11 CANH CANL
BLK WIRE
BLU WIRE
BRN WIRE
CAN I.C
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B
GAUGE FUSE
GND SIL PNK WIRE
GRN WIRE
HOT AT ALL TIMES ECU-B FUSE
HOT IN ON OR START
HOT IN ON OR START ECU-IG 2 FUSE
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
J/B 3 (BEHIND LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
SKID CONTROL ECU (BEHIND LEFT SIDE OF DASH)
TIRE PRESSURE WARNING ANTENNA, RECEIVER (LEFT "C" PILLAR)
TIRE PRESSURE WARNING ECU (BEHIND RIGHT SIDE OF DASH)
TIRE PRESSURE WARNING RESET SWITCH
TIRE)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Tire pressure monitoring circuit -> 1 4 2 5 RDA GND RSSI
