Toyota Prius II (2003-2005) Supplemental restraints circuit

-SR -SL +SR +SL 1 2 3 4 5 6 7 8 (PINS 9 THRU 14: NOT USED) 15 16 17 18 19 20 21 22 23 24 AIR BAG SENSOR ASSEMBLY (BEHIND LOWER CENTER OF DASH) BLK WIRE BQ (RIGHT REAR OF VEHICLE) DSP+ DBE+ DSP- DBE- VUPD VUCD ESD ESCD ESCP ESP VUCP VUPP GRN WIRE J/C 32 (RIGHT REAR OF VEHICLE) LA TC SIL LEFT CURTAIN SHIELD AIRBAG SENSOR LEFT CURTAIN SHIELD AIRBAG SQUIB LEFT FRONT AIRBAG SENSOR LEFT PRETENSIONER LEFT SIDE AIRBAG SENSOR LEFT SIDE AIRBAG SQUIB P- P+ D+ D- PBE PP- PP+ ICP+ ICP- SFP- SFP+ RED WIRE RIGHT CURTAIN SHIELD AIRBAG SENSOR RIGHT CURTAIN SHIELD AIRBAG SQUIB RIGHT FRONT AIRBAG SENSOR RIGHT FRONT BUCKLE SWITCH RIGHT PRETENSIONER RIGHT SIDE AIRBAG SENSOR RIGHT SIDE AIRBAG SQUIB SEAT POSITION AIRBAG SENSOR SEAT POSITION SENSOR BUCKLE SWITCH VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/PNK WIRE YEL/RED WIRE

BLK WIRE BLU WIRE BRN WIRE CENTER CONNECTOR 1 (BEHIND LEFT SIDE OF DASH) CENTER CONNECTOR 2 (BEHIND RIGHT SIDE OF DASH) COMBINATION METER DATA LINK CONNECTOR 3 (BEHIND LOWER LEFT SIDE OF DASH) DOME FUSE DRIVER SIDE J/B (BEHIND LEFT END OF DASH) DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) GAUGE FUSE GRN WIRE HOT AT ALL TIMES HOT IN ON OR START HYBRID VEHICLE CONTROL ECU (BEHIND RIGHT SIDE OF DASH) IGN FUSE IH (ABOVE LEFT KICK PANEL) II (BEHIND CENTER OF DASH) J/C 6 (BEHIND RIGHT END OF DASH) LT GRN WIRE PNK WIRE RED WIRE SRS INDICATOR VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/PNK WIRE YEL/RED WIRE
