Immobilizer circuit for Toyota Prius I facelift (2000-2003)

1 2 3 4 5 6 7 8 9 10 11 12 +B IG BLK/RED WIRE BLK/WHT WIRE BLU/BLK WIRE BRN WIRE CENTER CLUSTER SWITCH DATA LINK CONNECTOR (DLC) 3 (BEHIND LOWER LEFT SIDE OF DASH) ECU-B FUSE FCVC FORCED ENTRY CIRCUIT HOT AT ALL TIMES HYBRID VEHICLE CONTROL ECU (BEHIND RIGHT SIDE OF DASH, FORWARD OF GLOVE BOX) IGNITION SWITCH IND CTY KSW HEVC INSTRUMENT PANEL J/B INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH) J/C 10 (ON LEFT END OF DASH) J/C 11 (BEHIND LEFT END OF DASH) J/C 12, J/C 13 (BEHIND UPPER LEFT CENTER OF DASH) J/C 20 (BEHIND UPPER LEFT CENTER OF DASH) J/C 24 (BEHIND UPPER LEFT CENTER OF DASH) J/C 24, J/C 25 (BEHIND UPPER LEFT CENTER OF DASH) J/C 27, J/C 28 (BEHIND UPPER LEFT CENTER OF DASH) LEFT FRONT DOOR COURTESY SWITCH LOCK LT GRN/BLK WIRE RADIO, PLAYER RED/GRN WIRE RED/WHT WIRE RUN WIRE TRANSPONDER KEY COMPUTER (BEHIND UPPER LEFT SIDE OF DASH) UNLOCK WARNING SWITCH WHT/BLK WIRE
